Токарные инструменты Iscar (часть 1) 2026 - страница 512

TOOLS FOR ALUMINUM WHEELS LF DTF50 SVXCR-16X2 DMIN 95º ISO Double Pocket Boring LDRED_2 LF_2 Heads with Dovetail Connection 14.5 VCGT 16 Inserts for Machining WF2 95˚ Aluminum Wheels WF 112.5˚ WB 7.5 LDRED Right hand shown Designation DMIN WF WF2 LF LF_2 LDRED LDRED_2 WB Insert DTF50 SVXCR-16X2 50.00 21.00 28.0 110.00 87.00 83.0 60.0 50.00 VCGT 16... For inserts, see pages: VCGT-AS (269) • VCGT-DW (PCD) (515) For holders, see pages: VDI-DTF50 (510) Spare Parts Designation DTF50 SVXCR-16X2 SR 16-236 T-15/5 WF LS Right view VDI-DTF50E-L60R QUICK-CHANGE Holder with a Dovetail Connection for LPR External Turning Aluminum Wheels with CUT-GRIP Heads DF DCONMS LF Designation WF LF LPR LS DF DCONMS VDI40-DTF50E-L60R 30.00 60.00 87.50 63.0 83.00 40.00 VDI50-DTF50E-L60R (1) 37.00 60.00 87.50 78.0 98.00 50.00 (1) on request For tools, see pages: DTF50 FSHDR-8 (508) Spare Parts Designation VDI-DTF50E-L60R SR M10X45 DIN912 HW8 L208 OR 5X1N 1 2 VDI-DTF50 LF LS QUICK-CHANGE Holder with 50 Dovetail Connection Internal WF Turning Aluminum Wheels with 50 DCONMS DF CUT-GRIP and ISOTURN Heads Designation WF LF LS DF DCONMS Fig. VDI40-DTF50F31L140R 31.00 140.00 63.0 83.00 40.00 2 VDI40-DTF50L110 0.00 110.00 63.0 83.00 40.00 1 VDI40-DTF50L140 0.00 140.00 63.0 83.00 40.00 1 VDI40-DTF50L170 0.00 170.00 63.0 83.00 40.00 1 VDI50-DTF50F31L140R (1) 31.00 140.00 78.0 98.00 50.00 2 VDI50-DTF50L110 (1) 0.00 110.00 78.0 98.00 50.00 1 VDI50-DTF50L140 (1) 0.00 140.00 78.0 98.00 50.00 1 VDI50-DTF50L170 (1) 0.00 170.00 78.0 98.00 50.00 1 (1) on request For tools, see pages: DTF50 FSHIUR (509) • DTF50 SVXCR-16X2 (510) • DTF50 SVXCR-22 (509) Spare Parts Designation VDI-DTF50 SR M10X45 DIN912 HW8 L208 510 ISCAR
