TURNING INSERTS 80° 95º CCET-WF 95º 95º 80° Rhombic Inserts with 86° a 7° Positive Flank and a IC D1 Wiper Near the Corner for RE 7° High Feed Finishing 0.3 RE L S Dimensions Recommended Machining Data ap f IC907 Designation L IC S RE D1 (mm) (mm/rev) CCET 0602005-WF 6.30 6.35 2.38 0.05 2.80 • 0.05-2.00 0.01-0.20 CCET 09T3005-WF 9.50 9.52 3.97 0.05 4.40 • 0.05-2.00 0.01-0.20 • For user guide and cutting speed recommendations, see pages 160-170,274-278 For tools, see pages: A/E/S-SCLCR/L (146) • AVC-SCLCR/L (121) • C#-SCLCR/L-JHP (71) • E-SCLCR/L-HEAD (145) • NQCH-SCACR/L-S-JHP (72) • PCLCR/L-S (72) • PCLCR/L-S-JHP (73) • PCLCR/L-S-JHP-MC (73) • SBTT#-SCLCR/L-JHP (418) • SCACR/L-S (72) • SCLCR-PAD (71) • SCLCR/L (70) • SCLCR/L-PAD-JHP (71) 80° 95º CCMT-WG 95º 95º 80° Rhombic Inserts with a 7° Positive Flank and a IC D1 Wiper Near the Corner for 7° High Feed Finishing RE L S Dimensions Tough 1 Hard Recommended Machining Data ap f IC8250 IC807 Designation L IC S RE D1 IC907 (mm) (mm/rev) CCMT 060204-WG 6.30 6.35 2.38 0.40 2.80 • • 0.40-2.00 0.10-0.35 CCMT 09T304-WG 9.70 9.52 3.97 0.40 4.40 • 0.40-2.00 0.14-0.30 CCMT 09T308-WG 9.70 9.52 3.97 0.80 4.40 • 0.50-2.50 0.20-0.38 CCMT 120408-WG 12.90 12.70 4.76 0.80 5.50 • 0.50-3.00 0.20-0.36 • For user guide and cutting speed recommendations, see pages 160-170, 274-278. For tools, see pages: A/E/S-SCLCR/L (146) • AVC-SCLCR/L (121) • C#-SCLCR/L-JHP (71) • E-SCLCR/L-HEAD (145) • PCLCR/L-S (72) • PCLCR/L-S-JHP (73) • PCLCR/L-S-JHP-MC (73) • SBTT#-SCLCR/L-JHP (418) • SCLCR-PAD (71) • SCLCR/L (70) • SCLCR/L-PAD-JHP (71) 75˚ EPGT-F1P 11˚ 100º 75° Rhombic Inserts with a Positive Flank for Very Low Finish IC D1 Turning Conditions on Steel RE L S Dimensions Recommended Machining Data ap f IC908 Designation L IC S RE D1 (mm) (mm/rev) EPGT 03X101-F1P 3.70 3.57 1.39 0.10 1.90 • 0.10-0.50 0.01-0.05 EPGT 03X102-F1P 3.70 3.57 1.39 0.20 1.90 • 0.10-0.50 0.02-0.10 EPGT 03X104-F1P 3.70 3.57 1.39 0.40 1.90 • 0.10-0.50 0.05-0.15 • For user guide and cutting speed recommendations, see pages 160-170, 274-278 For tools, see page: A/E-SEXPR/L-03 (147) 238 ISCAR
