TURNING INSERTS 45º 90° 45º SNMM-NR 75º 75º Single-Sided Square Inserts with a Special Chipformer IC=L 45° 75º for Roughing Machining RE S Dimensions Tough 1 Hard Recommended Machining Data ap f IC8350 IC8250 IC8150 Designation IC S RE (mm) (mm/rev) SNMM 190616-NR 19.05 6.35 1.60 • 2.50-8.00 0.35-1.00 SNMM 250724-NR 25.40 7.94 2.40 • • • 5.00-15.00 0.35-1.00 • For user guide and cutting speed recommendations, see pages 160-170, 274-278 For tools, see pages: DSBNR/L (52) • DSDNN (50) • DSSNR/L (51) • PSBNR/L (56) • PSDNN (53) • PSSNR/L (54) RE LOMX-H6P 75 º Tangential Inserts with 4 Cutting Edges for High Metal Removal INSL=L of up to 35 mm D.O.C. on Steel W1 S Dimensions Tough 1 Hard Recommended Machining Data IC8250 IC8150 ap f Designation W1 INSL S RE (mm) (mm/rev) LOMX 402224-H6P 14.40 40.30 22.60 2.40 • • 7.00-35.00 1.00-2.00 • For user guide and cutting speed recommendations, see pages 160-170, 274-278 For tools, see page: PLBOR/L (57) Application Range H6P Chipformer ap (mm) 45 40 35 30 25 20 15 10 1 2 f (mm/rev) 225
