TURNING TOOLS GAMP 95° C#-PWLNR/L-08-JHP 95° Lever Lock Tools with CAMFIX Exchangeable Shanks and 4° ECA Channels for High-Pressure 4° Central coolant direction DCONMS Bar Max Coolant Carrying Trigon Inserts (8° rotation adjustment) WF L3 LF Right hand tool shown Designation DCONMS WF LF L3 ECA GAMP(1) MIID(2) CP(3) DCP(4) C6 PWLNR/L-45065-08-JHP 63.00 45.00 65.00 42.70 55.0 -6.0 WNMG 08.. 300 1 • For user guide, see pages 6-7,104-110 (1) Rake angle axial (2) Master insert identification (3) Coolant pressure (Bar) (4) 1 - Slot for data chip, 0 - Without slot for data chip For inserts, see pages: WNMG-CERMET (173) • WNMG-F3S (176) • WNMG-F3P (172) • WNMG-M3P (173) • WNMG-F3M (175) • WNMG-M3M (175) • WNMG-TF (178) • WNMG-GN (179) • WNMG-NR (179) • WNMG-PP (178) • WNMG-VL (177) • WNMG-TNM (180) • WNMG-NF (176) • WNMM-NM (179) • WNMG-WF (177) • WNMA/WNMA-WG (180) • WNMG-WG (177) Spare Parts Designation C6 PWLNR/L-45065-08-JHP TWN 423 SP 4 LR 4 SR 117-2010 T-8/5 PN 3-4 CU-CW-JHP HW 3.0 LR 4DHTL (MR INJ)* * Optional, to be ordered separately LH 95° DWLNR/L 95° External 95° Lead Tools Carrying HF H Negative WNMG Trigon Inserts WF B LF Right hand tool shown Designation H HF B LF LH WF MIID(1) DWLNR/L 1616H-06 16.0 16.0 16.0 100.00 26.0 16.00 WNMG 0604 DWLNR/L 2020K-06 20.0 20.0 20.0 125.00 26.0 25.00 WNMG 0604 DWLNR/L 2525M-06 25.0 25.0 25.0 150.00 24.0 32.00 WNMG 0604 DWLNR/L 2020K-08 20.0 20.0 20.0 125.00 35.0 25.00 WNMG 0804 DWLNR/L 2525M-08 25.0 25.0 25.0 150.00 35.0 32.00 WNMG 0804 DWLNR/L 3232P-08 32.0 32.0 32.0 170.00 35.0 40.00 WNMG 0804 (1) Master insert identification For inserts, see pages: WNMG-F3S (176) • WNMX-M3/4MW (181) • WNMX-M3/4PW (181) • WNMG-F3P (172) • WNMG-M3P (173) • WNMG-CERMET (173) • WNGG-F3N (266) • WNMG-F3M (175) • WNMG-M3M (175) • WNMG-TF (178) • WNMG-GN (179) • WNMG-NR (179) • WNMG-PP (178) • WNMG-VL (177) • WNMG-TNM (180) • WNMG-SF (176) • WNMG-NF (176) • WNMM-NM (179) • WNMG-WF (177) • WNMA/WNMA-WG (180) • WNMG-WG (177) Spare Parts Designation DWLNR/L 1616H-06 RWT 322 RWT 3-2* SR 40090I LCGR-3 SR RC3 KSP 3 HW 2.5 DWLNR/L 2020K-06 RWT 322 RWT 3-2* SR 40090I LCGR-3 SR RC3 KSP 3 HW 2.5 DWLNR/L 2525M-06 RWT 322 RWT 3-2* SR 40090I LCGR-3 SR RC3 KSP 3 HW 2.5 DWLNR/L 2020K-08 RWT 443 RWT 443-TNM* TWH 4* SR 14-506 M4X0.7 LCGR-4 SR 10400270-25.5 T-15/5 DWLNR/L 2525M-08 RWT 443 RWT 443-TNM* TWH 4* SR 14-506 M4X0.7 LCGR-4 SR 10400270-25.5 T-15/5 DWLNR/L 3232P-08 RWT 443 RWT 443-TNM* TWH 4* SR 14-506 M4X0.7 LCGR-4 SR 10400270-25.5 T-15/5 * Optional, to be ordered separately 13
