TURNING INSERTS 80° CPGT-SM 95º 80° Rhombic Inserts with an 11° Positive Flank for IC D1 Semi-Finishing and Finish Turning on Soft Materials 11° RE L and Exotic Alloys S Dimensions Recommended Machining Data ap f IC907 Designation L IC S RE D1 (mm) (mm/rev) CPGT 060201-SM 6.45 6.35 2.38 0.10 2.80 • 0.25-2.00 0.05-0.20 CPGT 060202-SM 6.45 6.35 2.38 0.20 2.80 • 0.25-2.00 0.05-0.30 CPGT 060204-SM 6.45 6.35 2.38 0.40 2.80 • 0.50-3.00 0.10-0.35 CPGT 09T301-SM 9.67 9.52 3.97 0.10 4.40 • 0.25-2.00 0.05-0.25 CPGT 09T302-SM 9.67 9.52 3.97 0.20 4.40 • 0.50-2.50 0.10-0.30 CPGT 09T304-SM 9.67 9.52 3.97 0.40 4.40 • 0.60-3.50 0.10-0.35 • For user guide and cutting speed recommendations, see pages 160-170, 274-278 95º 80° CPMT-PF 95º 95º 80° Rhombic Inserts with a Positive Flank for IC D1 Semi-Finishing and Finishing on Soft Materials and 11° RE L Exotic Alloys S Recommended Dimensions Tough 1 Hard Machining Data ap f IC6025 IC6015 IC830 IC807 IC907 Designation L IC S RE D1 (mm) (mm/rev) CPMT 060204-PF 6.30 6.35 2.38 0.40 2.80 • • • • • 0.50-2.50 0.04-0.30 CPMT 060208-PF 6.30 6.35 2.38 0.80 2.80 • • • 0.50-2.50 0.08-0.30 CPMT 09T304-PF 9.50 9.52 3.97 0.40 4.40 • • • 0.50-3.00 0.05-0.35 CPMT 09T308-PF 9.50 9.52 3.97 0.80 4.40 • • • • • 0.50-3.50 0.10-0.35 • For user guide and cutting speed recommendations, see pages 160-170, 274-278 239
