TURNING TOOLS 27° MAX C#-SDJCR-JHP 93° Bar Max Screw Clamp Tools with CAMFIX Shanks and Channels for High- 58° Pressure Coolant Carrying DCONMS Positive 55° Rhombic Inserts WF 93° LF Right hand tool shown Designation DCONMS WF LF MIID(1) CP(2) DCP(3) C3 SDJCR-22040-11-JHP 32.00 22.00 40.00 DC.. 11T3 140 0 • For user guide, see pages 6-7,104-110 (1) Master insert identification (2) Coolant pressure (Bar) (3) 1 - Slot for data chip, 0 - Without slot for data chip For inserts, see pages: DCGT-F1M-12P (243) • DCGT-F1M-20P (244) • DCMT-CERMET (243) • DCMT-F3P (240) • DCMT-M3P (241) • DCMT-M3M (241) • DCMT/DCGT-PF (245) • DCMT/DCGT-SM (246) • DCET-WF (247) • DCGT-AS (270) • DCGT-AF (271) • DCMT-14 (247) • DCMT/DCGT (246) Spare Parts Designation C3 SDJCR-22040-11-JHP TDC 3-1P SR TC-3P SR 16-236 P T-15/5 CH-1.9D-JHP WASHER 4.2X5.6X0.5 SR M4X4 DIN913 TL360 HW 4.0 OAL 27° MAX SDJCR-PAD Holder: MAHPL 93° Screw Lock Adapter Carrying Holder: MAHR OAH HF 55° Diamond Inserts with 7° Clearance Angle WF (holder) 17.2 WF (assembly) WF WF WB_2 WF(Assembly)= WF(Holder)+WF Designation HF OAH OAL WF WB_2(1) MIID(2) SDJCR-07-PAD 24.0 28.00 42.00 7.50 5.2 DCMT/DCGT 0702 SR 14-548 T-7/5 • WF (assembly) = WF (holder) + WF (1) Rake angle axial (2) Master insert identification For inserts, see pages: DCGT-F1M-12P (243) • DCGT-F1M-20P (244) • DCMT-F3P (240) • DCMT-M3P (241) • DCMT-M3M (241) • DCMT/DCGT-PF (245) • DCMT/DCGT-SM (246) • DCET-WF (247) • DCGT-AS (270) • DCMT/DCGT (246) For holders, see pages: C#-MAHPD-JHP (698) • MAHPR/L-JHP (308) • MAHPR/L (307) • MAHR/L (306) • IM-MAHPD (707) • C#-MAHD (697) • C#-MAHPD (698) • C#-MAHDR-45 (696) • HSK A63WH-MAHUR/L (706) • HSK A63WH-MAHDR-45 (705) • HSK A63WH-MAHDOR (705) • HMSN-New Britain (537) OAL 27° MAX SDJCR/L-PAD-JHP 93° Screw Lock Adapter with HF OAH High-Pressure Coolant Mounts 55° Diamond Inserts CNT with 7° Clearance Angle WB_2 WF Designation HF OAL OAH WF WB_2 MIID(1) CNT SDJCR/L-07-PAD-JHP 24.0 52.80 33.00 15.00 10.0 DCMT/DCGT 0702 M4 SR 14-548 T-7/5 SR M4X4 DIN913 TL360 SR M3X3 DIN913 TL360 SDJCR/L-11-PAD-JHP 24.0 52.80 33.00 15.00 10.0 DCMT/DCGT 11T3 M4 SR 16-236 P T-15/5 SR M4X4 DIN913 TL360 SR M3X3 DIN913 TL360 New (1) Master insert identification For inserts, see pages: DCET-WF (247) • DCGT-AF (271) • DCGT-AS (270) • DCGT-F1M-12P (243) • DCGT-F1M-20P (244) • DCMT-14 (247) • DCMT-CERMET (243) • DCMT-F3P (240) • DCMT-M3M (241) • DCMT-M3P (241) • DCMT/DCGT (246) • DCMT/DCGT-PF (245) • DCMT/DCGT-SM (246) For holders, see pages: ABC MAHDR-#-XL-JHP (884) • C#-MAHPD-JHP (698) • DT##/2 MAHD#-#-XL-JHP (860) • MAHPR/L-JHP (308) • MS##-##-MG-JHP (859) • MS-ES#####-GWS-MG-JHP (861) • TR TNK36 MAHDL-R-XL-JHP (884) • TR45 MAHDR-#-XL-JHP (883) • TR45TNL MAHDN-R-XL-JHP (883) • V## MAHD#-#-XL-##-JHP (880) • V## MAHD-XL-JHP (881) 78 ISCAR
