TOOLS FOR MINIATURE PARTS B Y-PCHRS-17-JHP Y-Axis Screw Lock JETCUT Integral Tools for 5 Edged Inserts for HF HH OAH Grooving, Parting, and Recessing H Bar Max on Swiss-Type Machines Dmax LH WF LF OAL Designation H B HH LH HF WF OAH LF OAL D max(1) Y-PCHRS 12-17-JHP 12.0 12.0 6.0 20.0 12.0 8.60 18.00 100.00 105.50 25.0 (2) Y-PCHRS 16-17-JHP 16.0 16.0 2.0 20.0 16.0 12.30 18.00 125.00 130.50 38.0 (2) • Use right-hand inserts on right-hand tools and vice versa (1) Maximum workpiece diameter for grooving operation (2) for grooving For inserts, see pages: PENTA 17-ER/EL (344) • PENTA 17-MT-RS/LS (438) • PENTA 17-NP-RS/LS (344) • PENTA 17-NX-RS (345) • PENTA 17-P-RS/LS (341) • PENTA 17-P-RS/LS (full radius) (343) • PENTA 17-WT-RS/LS (438) • PENTA 17R/L-P-RS (342) Spare Parts Designation Y-PCHRS-17-JHP SR M4-39432L T-1508/5 HW 5/32" SR 5/16UNF TL360 LH CDX NQCH-PCHR/L-S-JHP OAH Screw Lock JETCUT Modular HF Heads Carrying PENTA Inserts for HBL HBH OAW LB Grooving, Parting, and Recessing Bar Max CWN-CWX on Swiss-Type Machines OAL Right hand tool shown Designation HF OAW LB OAH HBH LH OAL HBL CWN(2) CWX(3) CDX Insert NQCH12-PCHR/LS-17-JHP 12.0 20.00 21.00 24.40 6.0 17.0 29.80 17.0 0.25 3.18 4.00 PENTA 17 NQCH12R-PCHLS-17-JHP (1) 12.0 20.00 21.00 24.40 6.0 17.0 29.80 17.0 0.25 3.18 4.00 PENTA 17 NQCH16-PCHR/LS-17-JHP 16.0 20.00 21.00 24.50 2.0 17.0 29.80 17.0 0.25 3.18 4.00 PENTA 17 NQCH16R-PCHLS-17-JHP (1) 16.0 20.00 21.00 24.50 2.0 17.0 29.80 17.0 0.25 3.18 4.00 PENTA 17 • Use only RH Shank with RH Head and LH Shank with LH Head exept NQCH12R/16R... heads. (1) The head is dedicated for the right hand machines and to be mounted on the right hand holder only. (2) Minimum cutting width (3) Maximum cutting width For inserts, see pages: PENTA 17-ER/EL (344) • PENTA 17-MT-RS/LS (438) • PENTA 17-NP-RS/LS (344) • PENTA 17-NX-RS (345) • PENTA 17-P-RS/LS (341) • PENTA 17-P-RS/LS (full radius) (343) • PENTA 17-WT-RS/LS (438) • PENTA 17R/L-P-RS (342) For holders, see pages: NQCH-JHP (424) Spare Parts Designation NQCH12-PCHLS-17-JHP SR M4-39432 T-1508/5 NQCH12-PCHRS-17-JHP SR M4-39432L T-1508/5 NQCH12R-PCHLS-17-JHP SR M4-39432 T-1508/5 NQCH16-PCHLS-17-JHP SR M4-39432 T-1508/5 NQCH16-PCHRS-17-JHP SR M4-39432L T-1508/5 NQCH16R-PCHLS-17-JHP SR M4-39432 T-1508/5 433
