GROOVE-TURN MAHR/L-JHP-MC H HF Bar Max Holders with Bottom Inlets for HBH High-Pressure Coolant Channels OAL Carrying MODULAR-GRIP HBKW WF (shank) Left-hand shown Grooving and Turning Adapters B WF (assembly) • WF(assembly)= 1.2 WF (adapter) WF(shank)+WF(adapter) Designation H B OAL HBH WF(1) HBKW HF MAHR/L 20-JHP-MC 20.0 20.0 98.00 10.0 14.0 6.00 20.0 MAHR/L 25-JHP-MC 25.0 25.0 98.00 5.0 19.0 - 25.0 • For CDX, refer to the adapters data. (1) WF(shank) For tools, see pages: HFPAD-JHP (642) • PCADRS/LS-JHP (354) • SCLCR/L-PAD-JHP (71) • TGPAD-JHP (298) • CGPAD-JHP (309) • DGPAD-JHP (538) • HGPAD-JHP (291) • PCADR/L-JHP (353) • TAGPAD-JHP (562) • CGPAD (308) • DGAD-B-D (538) • DGAD/HGAD (537) • HFPAD-3 (643) • HFPAD-4 (643) • HFPAD-5 (644) • HFPAD-6 (644) • HGPAD (291) • PCADR/L (353) • TGAD (560) • TGPAD (297) Spare Parts Designation MAHR/L-JHP-MC SR M6X20-XT HW 5.0 SR M5-04451 T-20/5 SR M6X12DIN6912 OR 5X1N MAHPR/L HF H Holders for Perpendicularly Mounted Adapters suitable LH HBH OAL for all GRIP Systems B Right-hand shown Designation H B HF OAL LH HBH MAHPR/L 20 20.0 20.0 20.0 140.00 25.0 10.0 MAHPR/L 25 25.0 25.0 25.0 140.00 25.0 5.0 MAHPR/L 32 32.0 32.0 32.0 150.00 25.0 - For tools, see pages: CGPAD (308) • DGAD-B-D (538) • DGAD/HGAD (537) • HFPAD-3 (643) • HFPAD-4 (643) • HFPAD-5 (644) • HFPAD-6 (644) • HGPAD (291) • PCADR/L (353) • SCLCR-PAD (71) • SDJCR-PAD (78) • SVJCR-PAD (88) • SWAPR-PAD (96) • TGAD (560) • TGPAD (297) Spare Parts Designation MAHPR/L SR M5-04451 T-20/5 SR 14-519 SR M6X20-XT(a) HW 5.0 SR M6X6DIN551 14H/22H (a) For CGPAD, HGPAD, TGPAD and HFPAD adapters. Supplied with the tools. 307
