GROOVE-TURN OAL TGPAD-JHP Bar Max TOP-GRIP Adapters with OAH HF Channels for High-Pressure Coolant Carrying TGMF / LH CDX TGMP Groove-Turn Inserts WB_2 WB CW WF Left-hand shown Designation CWN(1) CWX(2) CDX(3) WF WB WB_2 LH OAL HF OAH TGPAD 3R/L-T9-JHP 3.00 3.00 9.00 4.00 2.40 5.2 12.7 37.20 24.0 30.00 TGPAD 4R/L-T16-JHP 4.00 5.00 16.00 3.50 3.40 5.2 17.2 41.70 24.0 30.00 TGPAD 5R/L-T16-JHP 5.00 5.00 16.00 3.00 4.40 5.2 17.2 41.70 24.0 30.00 TGPAD 6R/L-T22-JHP 6.00 6.35 22.00 3.50 5.00 6.0 23.2 47.10 24.0 32.00 • For user guide, see pages 475-492 (1) Minimum cutting width (2) Maximum cutting width (3) Grooving depth is limited by the insert For inserts, see pages: TGMF (full radius) (299) • TGMF/P (299) Flow Rate vs. Pressure 70 Bar 100 Bar 140 Bar Flow Rate Flow Rate Flow Rate Designation (liters/min) (liters/min) (liters/min) TGPAD 3R/L-T9-JHP 11-17 17-23 23-26 TGPAD 4R/L-T16-JHP 20-25 25-31 31-34 TGPAD 5R/L-T16-JHP 27-33 33-39 39-43 TGPAD 6R/L-T22-JHP 30-35 35-41 41-44 OHN-OHX CWN-CWX TGHN-D Double-Ended Blades Carrying Utility Inserts for HF H Grooving and Turning OAL WB Designation H CWN(1) CWX(2) OHN(3) OHX(4) HF OAL WB MIID(5) TGHN 26-3D 26.0 3.00 3.00 10.0 15.0 21.4 110.00 2.40 TGMF 3 TGHN 26-4D 26.0 4.00 5.00 10.0 15.0 21.4 110.00 3.20 TGMF 4, TGMF/P 5 TGHN 26-5D 26.0 5.00 5.00 10.0 20.0 21.4 110.00 4.00 TGMF/P 5 TGHN 32-3D 32.0 3.00 3.00 10.0 18.0 24.8 150.00 2.40 TGMF 3 TGHN 32-4D 32.0 4.00 5.00 12.0 21.0 24.8 150.00 3.20 TGMF 4, TGMF/P 5 TGHN 32-5D 32.0 5.00 5.00 12.0 26.0 24.8 150.00 4.00 TGMF/P 5 TGHN 32-6D 32.0 6.00 6.35 16.0 26.0 24.8 150.00 5.20 TGMF 6 • Use the drilled holes on blade for min. and max. overhang • Grooving depth is limited by the insert • For user guide, see pages 475-492 (1) Minimum cutting width (2) Maximum cutting width (3) Minimum overhang (4) Maximum overhang (5) Master insert identification For inserts, see pages: TGMA (299) • TGMF (full radius) (299) • TGMF/P (299) For holders, see pages: SGTBU/SGTBN (690) • UBHCR/L (691) TGHN-S OHN-OHX CWN-CWX Single-Ended Blades Carrying Utility Inserts for HF H Grooving and Turning WB OAL Designation H CWN(1) CWX(2) OHN(3) OHX(4) HF OAL WB MIID(5) TGHN 32-3S 32.0 3.00 3.00 10.0 18.0 24.8 48.30 2.40 TGMF 3 TGHN 32-5S 32.0 5.00 5.00 12.0 25.0 24.8 54.00 4.00 TGMF/P 5 TGHN 32-6S 32.0 6.00 6.35 16.0 25.0 24.8 55.70 5.20 TGMF 6 • Use the drilled holes on blade for min. and max. overhang • Grooving depth is limited by the insert • For user guide, see pages 475-492 (1) Minimum cutting width (2) Maximum cutting width (3) Minimum overhang (4) Maximum overhang (5) Master insert identification For inserts, see pages: TGMA (299) • TGMF (full radius) (299) • TGMF/P (299) For holders, see pages: C#-TBU (696) • IM-TBU (707) • UBHCR/L (691) 298 ISCAR
