Токарные инструменты Iscar (часть 1) 2026 - страница 89

TURNING TOOLS 50° 105° MAX C#-SVJCR/L 93° Screw Lock Tools with CAMFIX Exchangeable Shanks 70 Carrying 35° Rhombic Inserts DCONMS Bar Max with 7° Clearance Angle WF LF Right hand tool shown Designation DCONMS WF LF CP(1) DCP(2) MIID(3) C4 SVJCR/L-27050-11 40.00 27.00 50.00 70 1 VC.. 1103 SR 14-560/S M2.5X0.45 T-8/5 EZ 83 C4 SVJCR/L-27050-16 40.00 27.00 50.00 70 1 VC.. 1604 TVC 3-1 SR TC-3 HW 2.5 SR 16-236 P T-15/5 EZ 83 C5 SVJCR-35060-11 50.00 35.00 60.00 70 1 VC.. 1103 SR 14-560/S M2.5X0.45 T-8/5 EZ 104 C5 SVJCR/L-35060-16 50.00 35.00 60.00 70 1 VC.. 1604 TVC 3-1 SR TC-3 HW 2.5 SR 16-236 P T-15/5 EZ 104 C6 SVJCR/L-45065-16 63.00 45.00 65.00 70 1 VC.. 1604 TVC 3-1 SR TC-3 HW 2.5 SR 16-236 P T-15/5 EZ 125 (1) Coolant pressure (Bar) (2) 1 - Slot for data chip, 0 - Without slot for data chip (3) Master insert identification For inserts, see pages: VCGT-F1M-12P (250) • VCGT-F1M-20P (250) • VCMT-FPC-CERMET (250) • VCMT-F3P (248) • VCMT-M3P (248) • VCMT-F3M (249) • VCMT-M3M (249) • VCMT-SM (251) • VCET-WF (251) • VCGT-AS (269) • VCMT-14 (252) • VCMW (252) • VCGT-DW (PCD) (515) GAMP 50° 105° MAX C#-SVJCR/L-JHP 93° Screw Lock Tools with CAMFIX Exchangeable Shanks 4° ECA Carrying 35° Rhombic Inserts Central coolant direction DCONMS Bar Max 4° with 7° Clearance Angle (8° rotation adjustment) WF L3 LF Right hand tool shown Designation DCONMS WF LF GAMP(1) ECA L3 MIID(2) CP(3) DCP(4) C3 SVJCL 22040-11-JHP 32.00 22.00 40.00 0.0 55.0 - VCMT 1103 300 0 C3 SVJCR-22040-11-JHP 32.00 22.00 40.00 0.0 55.0 - VCMT 1103 300 0 C4 SVJCR/L-27055-16-JHP 40.00 27.00 55.00 0.0 55.0 - VCMT 1604 300 1 C5 SVJCR/L-35060-16-JHP 50.00 35.00 60.00 0.0 55.0 - VCMT 1604 300 1 C6 SVJCR-45065-16-JHP 63.00 45.00 65.00 0.0 70.0 16.80 VCMT 1604 300 1 • For user guide, see pages 6-7,104-110 (1) Rake angle axial (2) Master insert identification (3) Coolant pressure (Bar) (4) 1 - Slot for data chip, 0 - Without slot for data chip For inserts, see pages: VCGT-F1M-12P (250) • VCGT-F1M-20P (250) • VCMT-FPC-CERMET (250) • VCMT-F3P (248) • VCMT-M3P (248) • VCMT-F3M (249) • VCMT-M3M (249) • VCMT-SM (251) • VCET-WF (251) • VCGT-AS (269) • VCMT-14 (252) • VCMW (252) • VCGT-DW (PCD) (515) Spare Parts Designation C3 SVJCR-22040-11-JHP SR 14-560 CH-1.9D-JHP T-8/5 C4 SVJCR/L-27055-16-JHP TVC 3-1 SR TC-3 T-15/5 SR 16-236 P CU-V-JHP T-8/5 HW 2.5 C5 SVJCR/L-35060-16-JHP TVC 3-1 SR TC-3 T-15/5 SR 16-236 P CU-V-JHP T-8/5 HW 2.5 C6 SVJCR-45065-16-JHP TVC 3-1 SR TC-3 T-15/5 SR 16-236 P CU-V-JHP T-8/5 HW 2.5 50° 105° MAX HSK A63WH-SVJCR/L 93° Tools with HSK Exchangeable Tapered Shanks Carrying Positive 35° Inserts for Mounting at DCONMS WF 20 15° on Turn-Mill Machines 78° LF Right hand tool shown Designation DCONMS LF WF DCP(1) MIID(2) HSK A63WH-SVJCR/L-J16 63.00 110.00 25.00 0 VC.. 1604 TVC 3-1 SR TC-3 HW 2.5 SR 16-236 P T-15/5 EZ 104 • Complies with ICTM standard (ISO 12164-3). • A cooling tube must be used with all coolant through HSK spindles (should be ordered separately). • For shank dimensions, see page 835 (1) 1 - Slot for data chip, 0 - Without slot for data chip (2) Master insert identification For inserts, see pages: VCMT-FPC-CERMET (250) • VCMT-F3P (248) • VCMT-M3P (248) • VCMT-F3M (249) • VCMT-M3M (249) • VCMT-SM (251) • VCGT-AS (269) • VCMT-14 (252) • VCMW (252) • VCGT-DW (PCD) (515) 87
