GROOVE-TURN 0.15 0.2 ±0.025 GITM (full radius) 30° 20° Full Radius CBN Tipped Inserts 7° for Grooving and Turning on IB20H IB50 / IB10H 15 Ref. Hard Ferrous Materials 200° BW DAXN RE CW HARD MATERIALS Dimensions Tough 1 Hard Recommended Machining Data ap f turn f groove IB20H IB10H IB50 Designation CW RE CWTOL(1) RETOL(2) BW DAXN(3) (mm) (mm/rev) (mm/rev) GITM 3.00K-1.50 3.00 1.50 0.020 0.050 2.40 160.0 • • • 0.00-0.30 0.03-0.10 0.02-0.06 GITM 4.00K-2.00 4.00 2.00 0.020 0.050 3.20 160.0 • • • 0.00-0.40 0.04-0.14 0.02-0.09 GITM 5.00K-2.50 5.00 2.50 0.020 0.050 3.90 160.0 • • 0.00-0.50 0.05-0.18 0.03-0.11 GITM 6.00K-3.00 6.00 3.00 0.020 0.050 5.00 160.0 • • • 0.00-0.60 0.06-0.22 0.04-0.13 GITM 8.00K-4.00 8.00 4.00 0.020 0.050 5.60 160.0 • 0.00-0.80 0.08-0.29 0.05-0.17 • DMIN for internal machining = 70 mm • For cutting speed recommendations and user guide, see pages 475-492 (1) Cutting width tolerance (+/-) (2) Corner radius tolerance (+/-) (3) Minimum axial grooving diameter For tools, see pages: Anti-Vibration Blades (312) • C#-GHDR/L (301) • CGHN 26-M (399) • CGHN 32-DGM (400) • CGHN 32-M (400) • CGHN-D (310) • CGHN-DG (310) • CGHN-S (309) • CGPAD (308) • CGPAD-JHP (309) • GHDR/L (short pocket) (302) • GHDR/L-JHP (short pocket) (303) • GHDR/L-JHP-MC (short pocket) (304) • GHGR/L (305) • GHMPR/L (300) • GHMR/L (300) • GHSR/L (428) • GHSR/L-JHP-SL (429) • NQCH-GHSR/L-JHP (428) ±0.025 GIPY Single-Ended Full Radius Sharp 7° 5 Edged Precision Inserts for 15.3 Ref. Profiling High Temperature Alloys CW RE BW Recommended Dimensions Tough 1 Hard Machining Data f turn f groove IC1017 IC320 IC806 IC907 IC804 IC20 IC07 IC4 Designation CW RE CWTOL(1) RETOL(2) BW (mm/rev) (mm/rev) GIPY 3.00-1.50 3.00 1.50 0.020 0.050 2.40 • • • • • • • 0.19-0.28 0.08-0.15 GIPY 4.00-2.00 4.00 2.00 0.020 0.050 3.20 • • • • • • • 0.22-0.37 0.10-0.20 GIPY 5.00-2.50 5.00 2.50 0.020 0.050 3.90 • • • • • • • 0.24-0.46 0.13-0.23 GIPY 6.00-3.00 6.00 3.00 0.020 0.050 5.00 • • • • • • 0.26-0.55 0.15-0.27 GIPY 8.00-4.00 8.00 4.00 0.020 0.050 5.60 • • • • • • 0.34-0.74 0.20-0.36 • Can cut arcs to 250° • DMIN for internal machining = 70 mm • For cutting speed recommendations and user guide, see pages 475-492 (1) Cutting width tolerance (+/-) (2) Corner radius tolerance (+/-) For tools, see pages: Anti-Vibration Blades (312) • C#-GHDR/L (301) • CGFG 51-P8 (661) • CGHN 26-M (399) • CGHN 32-DGM (400) • CGHN 32-M (400) • CGHN-D (310) • CGHN-DG (310) • CGHN-P8 (311) • CGHN-S (309) • CGHR/L-P8DG (311) • CGPAD (308) • CGPAD-JHP (309) • GHDR/L (short pocket) (302) • GHDR/L-JHP (short pocket) (303) • GHDR/L-JHP-MC (short pocket) (304) • GHGR/L (305) • GHMPR/L (300) • GHMR/L (300) • GHSR/L (428) • GHSR/L-JHP-SL (429) • NQCH-GHSR/L-JHP (428) 331
