TURNING INSERTS 45º 90° 45º SNMM-H4P 75º Single-Sided Square Inserts with a Strong Cutting Edge IC=L 45° for Extra Rough Turning RE S Dimensions Tough 1 Hard Recommended Machining Data IC8250 IC8150 ap f Designation IC RE S (mm) (mm/rev) SNMM 190624-H4P 19.05 2.40 6.35 • • 4.00-12.00 0.50-1.10 SNMM 250924-H4P 25.40 2.40 9.52 • • 5.00-15.00 0.55-1.50 • For user guide and cutting speed recommendations, see pages 160-170, 274-278 For tools, see pages: DSBNR/L (52) • DSDNN (50) • DSSNR/L (51) • PSBNR/L (56) • PSDNN (53) • PSSNR/L (54) 45º 90° 45º SNMM-H5P 75º Single-Sided Square Insert with a Strong Cutting Edge IC=L 45° for Extra Rough Turning RE S Dimensions Tough 1 Hard Recommended Machining Data ap f IC8250 IC8150 Designation IC RE S (mm) (mm/rev) SNMM 250924-H5P 25.40 2.40 9.52 • • 3.60-16.00 0.60-1.50 • For user guide and cutting speed recommendations, see pages 160-170, 274-278 For tools, see pages: PSBNR/L (56) • PSDNN (53) • PSSNR/L (54) 45º 90° 45º 45° SNMM-NM 75º Single-Sided Square Inserts for Roughing Applications IC=L 75º 75º RE S Dimensions Tough 1 Hard Recommended Machining Data ap f IC8250 IC830 Designation IC S RE (mm) (mm/rev) SNMM 190616-NM 19.05 6.35 1.60 • • 2.50-10.00 0.30-0.70 • For user guide and cutting speed recommendations, see pages 160-170, 274-278 For tools, see pages: DSBNR/L (52) • DSDNN (50) • DSSNR/L (51) • PSBNR/L (56) • PSDNN (53) • PSSNR/L (54) 224 ISCAR
