TOOLS FOR MINIATURE PARTS B Y-SCHR-22BF-JHP Y-Axis Screw Lock JETCUT Integral Tools for SWISSCUT HH HF OAH Inserts for Grooving and Turning H on Swiss-Type Machines Dmax WF LH LF Bar Max OAL Designation H B HH LH HF WF OAH LF OAL D max(1) Y-SCHR 12-22BF-JHP 12.0 12.0 13.0 20.0 12.0 9.00 25.00 100.00 105.50 25.0 (2) Y-SCHR 16-22BF-JHP 16.0 16.0 9.0 20.0 16.0 13.00 25.00 125.00 130.50 38.0 (2) (1) Maximum workpiece diameter for grooving operation (2) for grooving For inserts, see pages: SCIR-22-MTR-ISO (742) • SCIR/L-22-AD (409) • SCIR/L-22-AR/AL (409) • SCIR/L-22-BR/BL/BRA/BLA (409) • SCIR/L-22-ER/EL/ERA/ELA (410) • SCIR/L-22-MTR/MTL (726) • SCIR/L-22-N/R/L (411) • SCIR/L-22-NP (412) • SCIR/L-22-NX (412) Spare Parts Designation Y-SCHR 12-22BF-JHP HW 5/32" T-8/5 SR M4X0.7-19425 SR 5/16UNF TL360 Y-SCHR 16-22BF-JHP HW 5/32" T-8/5 SR M4X0.7-19425 SR 5/16UNF TL360 NQCH-SCHR/L-BF-JHP HF OAH Screw Lock JETCUT Modular Heads Carrying SWISSCUT LH OAW Inserts for Grooving and Turning Bar Max CWN-CWX on Swiss-Type Machines OAL Right hand tool shown Designation HF OAW LH OAH OAL CWN(2) CWX(3) Insert NQCH12-SCHR/L-22BF-JHP 12.0 20.00 24.0 17.30 32.80 0.50 2.50 SCIR/L-22 SR M4X0.7-19425 T-8/5 NQCH12R-SCHL-22BF-JHP (1) 12.0 20.00 24.0 17.30 32.80 0.50 2.50 SCIR/L-22 SR M4X0.7-19425 T-8/5 NQCH16-SCHR/L-22BF-JHP 16.0 20.00 24.0 21.10 32.80 0.50 2.50 SCIR/L-22 SR M4X0.7-19425 T-8/5 NQCH16R-SCHL-22BF-JHP (1) 16.0 20.00 24.0 21.10 32.80 0.50 2.50 SCIR/L-22 SR M4X0.7-19425 T-8/5 • Use only RH Shank with RH Head and LH Shank with LH Head exept NQCH12R/16R... heads. (1) The head is dedicated for the right hand machines and to be mounted on the right hand holder only. (2) Minimum cutting width (3) Maximum cutting width For inserts, see pages: SCIR-22-MTR-ISO (742) • SCIR/L-22-AD (409) • SCIR/L-22-AR/AL (409) • SCIR/L-22-BR/BL/BRA/BLA (409) • SCIR/L-22-ER/EL/ERA/ELA (410) • SCIR/L-22-MTR/MTL (726) • SCIR/L-22-N/R/L (411) • SCIR/L-22-NP (412) • SCIR/L-22-NX (412) For holders, see pages: NQCH-JHP (424) NQCH-Y-SCHR-BF-JHP HF HH OAH Screw Lock JETCUT Modular Heads Carrying SWISSCUT LH OAW Inserts for Grooving and Bar Max Turning in Y-Axis on Swiss-Type Machines OAL Right hand tool shown Designation HF OAH LH OAW HH OAL CWN(1) CWX(2) Insert NQCH12-Y-SCHR-22BF-JHP 12.0 25.00 20.0 20.00 13.0 34.30 0.50 2.50 SCIR/L-22-N/R/L SR M4X0.7-19425 T-8/5 NQCH16-Y-SCHR-22BF-JHP 16.0 25.00 20.0 20.00 9.0 34.30 0.50 2.50 SCIR/L-22-N/R/L SR M4X0.7-19425 T-8/5 • Use only RH Shank with RH Head and LH Shank with LH Head (1) Minimum cutting width (2) Maximum cutting width For inserts, see pages: SCIR-22-MTR-ISO (742) • SCIR/L-22-AD (409) • SCIR/L-22-AR/AL (409) • SCIR/L-22-BR/BL/BRA/BLA (409) • SCIR/L-22-ER/EL/ERA/ELA (410) • SCIR/L-22-MTR/MTL (726) • SCIR/L-22-N/R/L (411) • SCIR/L-22-NP (412) • SCIR/L-22-NX (412) For holders, see pages: NQCH-JHP (424) 408 ISCAR
