PARTING DGHFL... DGHFR... DGHFR...L DGHFL...R OAL CWN-CWX DGFHR/L-BC-JHP Parting and Grooving Reinforced HF H Blades with Channels for Min Max WB High-Pressure Coolant WB_2 Bar Max Carrying DO-GRIP Inserts CDX Designation CWN(1) CWX(2) WB_2 WB OAL H HF CDX(3) Insert DGFHR/L 32BC-3T33-JHP 3.00 3.18 7.9 2.40 111.00 32.0 24.8 33.00 DG. 3.. DGFHL 32BC-3T33R-JHP 3.00 3.18 7.9 2.40 111.00 32.0 24.8 33.00 DG. 3.. DGFHR 32BC-3T33L-JHP 3.00 3.18 7.9 2.40 111.00 32.0 24.8 33.00 DG. 3.. • For user guide, see pages 606-615 (1) Minimum cutting width • For DG: 1.0 insert - modify holder (2) Maximum cutting width (3) The specified limit refers to the tool For inserts, see pages: DGN-LF/LFT (546) • DGN-MF (541) • DGN-P (548) • DGN-T (541) • DGN-UT/UA (547) • DGN-Z (546) • DGN/DGNC/DGNM-C (539) • DGN/DGNM-J/JS/JT (544) • DGR-Z/ZS (547) • DGR/L-C DGRC/LC-C (540) • DGR/L-J/JS (545) For holders, see pages: TGTBU-JHP (559) SGC 340 T-2010/5 Spare Parts Designation DGFHL 32BC-3T33-JHP SR M4-21532 HW 3.0 SGC 340 SR M3X3DIN913 DGFHR 32BC-3T33-JHP SR M4-21532 HW 3.0 SGC 340 SR M3X3DIN913 DGFHL 32BC-3T33R-JHP SR M4-21532 HW 3.0 SGC 340 SR M3X3DIN913 DGFHR 32BC-3T33L-JHP SR M4-21532 HW 3.0 SGC 340 SR M3X3DIN913 OAL CWN-CWN LH DGFS H Blades for Multi-Spindle WB CUTDIA Machines, Replacement for WB_2 HSS and Brazed Tools a° Designation H CWN(7) CWX(8) CUTDIA(9) WB WB_2 OAL LH a° DGFS 0-12-2 (1) 12.7 1.90 2.50 32.0 1.60 3.2 110.00 32.0 0 EDG 33B* DGFS 0-17-2 (2) 17.4 1.90 2.50 35.0 1.60 3.2 110.00 32.0 0 EDG 33B* DGFS 0-17-3 (2) 17.4 3.00 3.18 60.0 2.40 3.2 110.00 32.0 0 EDG 33B* DGFS 5-17-2 (3) 17.4 1.90 2.50 35.0 1.60 3.2 110.00 32.0 5 EDG 33B* DGFS 5-17-3 (3) 17.4 3.00 3.18 60.0 2.40 3.2 110.00 32.0 5 EDG 33B* DGFS 5-17-4 (3) 17.4 4.00 4.00 60.0 3.20 3.2 110.00 32.0 5 EDG 33B* DGFS 5-22-2 (4) 22.2 1.90 2.50 50.0 1.60 3.2 150.00 32.0 5 EDG 33B* DGFS 5-22-3 (5) 22.2 3.00 3.18 75.0 2.40 3.2 150.00 32.0 5 EDG 33B* DGFS 5-22-4 (5) 22.2 4.00 4.00 80.0 3.20 3.2 150.00 32.0 5 EDG 33B* DGFS 5-24-3 23.8 3.00 3.18 80.0 2.40 3.2 150.00 32.0 5 EDG 33B* DGFS 5-28-2 (6) 28.5 1.90 2.50 65.0 1.60 3.2 150.00 32.0 5 EDG 33B* DGFS 5-28-4 (6) 28.5 4.00 4.00 100.0 3.20 3.2 150.00 32.0 5 EDG 33B* • DG..1.0 insert can be mounted into pocket sizes 2 and 3. in which case the pocket width has to be modified -see page 537 • For user guide, see pages 606-615 (1) Toolholder assembly X18-1,46,47-WT,160-CL,354-CL,701-ACL,702,702-CL,703,703-CL,704,704-CL,6921,6925 (2) Toolholder assembly E-7,47,102-CL,103-CL,161-A-CL,162-A-CL (3) Toolholder assembly 226,226-CL,275,275-CL,276-CL,361-CL,431,630,707-A,707-A-CL (4) Toolholder assembly 100-CL,274,277,277-CL,274-CL,370,383-CL, 6722,6754,6755,6854,6855,6922,51,51-CL,353-CL,167,370-CL (5) Toolholder assembly 100-CL,274,277,277-CL,274-CL,370,383-CL, 6722,6754,6755,6854,6855,51,51-CL,353-CL,167,370-CL (6) Toolholder assembly 278,278-CL,279,279-CL,280,280-CL,281,281-CL,375-CL,359-CL,372-CL,A6120,52,52-CL (7) Minimum cutting width • For DG: 1.0 insert - modify holder (8) Maximum cutting width (9) Maximum workpiece diameter for grooving operation * Optional, to be ordered separately For inserts, see pages: DGN-B (542) • DGN-LF/LFT (546) • DGN-T (541) • DGR/L-B (542) • GRIP-T (295) • GRIPA (296) • GRIPA (full radius) (296) • DGN/DGNC/DGNM-C (539) • DGR/L-C DGRC/LC-C (540) • DGN/DGNM-J/JS/JT (544) • DGR/L-J/JS (545) • DGN-P (548) • DGN-UT/UA (547) • DGN-WP (549) • DGN-Z (546) • DGR-P (548) • DGR-WP (549) • DGR-Z/ZS (547) • GRIP (294) • GRIP (full radius) (295) 527
