TURNING TOOLS LH 60° MAX SDNCN-13-SL HF H 62.5º Screw Lock Tools Carrying 55° Diamond Inserts with 7° Clearance Angle for High WF Rigidity in Profiling Applications B LF Designation H HF B LF LH WF MIID(1) SDNCN 1616H-13-SL 16.0 16.0 16.0 100.00 25.0 8.00 DCMT 13T5-SL SR M4X0.7-L9.6 IP15 TORX PLUS IP15X45 GREEN SDNCN 2020K-13-SL 20.0 20.0 20.0 125.00 25.0 10.00 DCMT 13T5-SL SR M4X0.7-L9.6 IP15 TORX PLUS IP15X45 GREEN SDNCN 2525M-13-SL 25.0 25.0 25.0 150.00 25.0 12.50 DCMT 13T5-SL SR M4X0.7-L9.6 IP15 TORX PLUS IP15X45 GREEN • Insert clamping torque 3 Nxm (1) Master insert identification For inserts, see pages: DCMT-F3P-SL (240) • DCMT-M3M-SL (242) • DCMT-PF-SL (244) • DCMT-SM-SL (245) GAMP 60° MAX C#-SDNCN-13-SL-JHP 62.5º Bar Max Screw Clamp Tools with CAMFIX Shanks and Channels for High- WF Pressure Coolant Carrying DCONMS Positive 55° Rhombic Inserts LF Designation DCONMS WF LF GAMP(1) MIID(2) CP(3) DCP(4) C3 SDNCN-00045-13-SL-JHP 32.00 0.50 45.00 0.0 DCMT 13T5-SL 140 0 C4 SDNCN-00060-13-SL-JHP 40.00 0.50 60.00 0.0 DCMT 13T5-SL 140 1 C5 SDNCN-00060-13-SL-JHP 50.00 0.50 60.00 0.0 DCMT 13T5-SL 140 1 • For user guide, see pages 6-7,104-110 (1) Rake angle axial (2) Master insert identification (3) Coolant pressure (Bar) (4) 1 - Slot for data chip, 0 - Without slot for data chip For inserts, see pages: DCMT-F3P-SL (240) • DCMT-M3M-SL (242) • DCMT-PF-SL (244) • DCMT-SM-SL (245) Spare Parts Designation C3 SDNCN-00045-13-SL-JHP CH-1.9D-JHP WASHER 4.2X5.6X0.5 SR M4X4 DIN913 TL360 SR M4X0.7-L9.5 IP15 C4 SDNCN-00060-13-SL-JHP CU-D-JHP SR M4X0.7-L9.6 IP15 T-8/5 C5 SDNCN-00060-13-SL-JHP CU-D-JHP SR M4X0.7-L9.6 IP15 T-8/5 60° LH MAX SDNCN 62.5º HF H Screw Lock Tools Carrying 55° Diamond Inserts with 7° Clearance Angle WF B LF Designation H HF B LF LH WF MIID(2) SDNCN 0808F-07 8.0 8.0 8.0 80.00 14.0 4.00 DC..0702 SR 14-548 T-7/5 SDNCN 1010F-07 10.0 10.0 10.0 80.00 14.5 5.00 DC..0702 SR 14-548 T-7/5 SDNCN 1010K-11S (1) 10.0 10.0 10.0 120.00 20.0 5.00 DC..11T3 SR 16-236 T-15/5 SDNCN 1212F-11 12.0 12.0 12.0 80.00 21.3 6.00 DC..11T3 SR 16-236 P T-15/5 SDNCN 1616H-11 16.0 16.0 16.0 100.00 21.0 8.00 DC..11T3 SR 16-236 P T-15/5 SDNCN 2020K-11 20.0 20.0 20.0 125.00 21.0 10.00 DC..11T3 SR 16-236 P T-15/5 SDNCN 2525M-11 25.0 25.0 25.0 150.00 30.0 12.50 DC..11T3 SR 16-236 P T-15/5 TDC 3-1P SR TC-3P HW 4.0 (1) For Swiss-type machines (2) Master insert identification For inserts, see pages: DCGT-AF (271) • DCGT-AS (270) • DCGT-F1M-12P (243) • DCGT-F1M-20P (244) • DCMT-14 (247) • DCMT-CERMET (243) • DCMT-F3P (240) • DCMT-M3M (241) • DCMT-M3P (241) • DCMT/DCGT (246) • DCMT/DCGT-PF (245) • DCMT/DCGT-SM (246) 83
