TURNING INSERTS 55° 60° 93º-95º MAX DNMG-M3M 62.5º 30º MAX Double-Sided 55° Rhombic 27° IC MAX Inserts for Machining Stainless 93° and Low Carbon Steel RE S L Recommended Dimensions Tough 1 Hard Machining Data ap f IC6025 IC6015 IC706 IC830 IC806 IC807 IC804 Designation L IC S RE (mm) (mm/rev) DNMG 110404-M3M 11.63 9.52 4.76 0.40 • • • • • • 0.50-3.50 0.12-0.40 DNMG 110408-M3M 11.63 9.52 4.76 0.80 • • • • • • 0.50-4.00 0.15-0.50 DNMG 110412-M3M 11.63 9.52 4.76 1.20 • • • • • 0.50-4.00 0.20-0.60 DNMG 150408-M3M 15.50 12.70 4.76 0.80 • • • • • • • 0.50-5.00 0.15-0.50 DNMG 150412-M3M 15.50 12.70 4.76 1.20 • • • • • 0.50-5.00 0.20-0.60 DNMG 150608-M3M 15.50 12.70 6.35 0.80 • • • • • • 0.50-5.00 0.15-0.50 DNMG 150612-M3M 15.50 12.70 6.35 1.20 • • • • • 0.50-5.00 0.20-0.60 • For user guide and cutting speed recommendations, see pages 160-170, 274-278 For tools, see pages: A/S-PDUNR/L (140) • AVC-DDUNR/L-VH (128) • C#-DDJNR/L (40) • C#-PDJNR/L-JHP (38) • DDJNR/L (39) • HSK A63WH-DDJNR/L (40) • HSK A63WH-DDNNN (41) • PDJNR/L (36) • PDJNR/L-JHP (37) • PDJNR/L-JHP-MC (37) • PDJNR/L-PAD-JHP (38) • S-DDUNR/L (139) • AVC-DDUNR/L (126) • DDJNR/L-JHP-MC (39) 55° 60° 93º-95º MAX DNMG-F3S 62.5º 30º MAX Double-Sided 55° Rhombic 27° IC MAX Inserts for Titanium and 93° Heat Resistant Materials for Finishing Applications RE L S Dimensions Tough 1 Hard Recommended Machining Data ap f IC706 IC806 IC804 Designation L IC S RE (mm) (mm/rev) DNMG 110404-F3S 11.63 9.52 4.76 0.40 • • • 0.10-1.50 0.05-0.32 DNMG 110408-F3S 11.63 9.52 4.76 0.80 • • • 0.10-1.50 0.10-0.40 DNMG 150404-F3S 15.50 12.70 4.76 0.40 • • • 0.10-1.50 0.05-0.32 DNMG 150408-F3S 15.50 12.70 4.76 0.80 • • • 0.10-1.50 0.10-0.40 DNMG 150604-F3S 15.50 12.70 6.35 0.40 • • • 0.10-1.50 0.05-0.32 DNMG 150608-F3S 15.50 12.70 6.35 0.80 • • • 0.10-1.50 0.10-0.40 • For user guide and cutting speed recommendations, see pages 160-170, 274-278 For tools, see pages: A/S-PDUNR/L (140) • AVC-DDUNR/L (126) • AVC-DDUNR/L-VH (128) • C#-DDJNR/L (40) • C#-PDJNR/L-JHP (38) • DDJNR/L (39) • DDJNR/L-JHP-MC (39) • HSK A63WH-DDJNR/L (40) • HSK A63WH-DDNNN (41) • PDJNR/L (36) • PDJNR/L-JHP (37) • PDJNR/L-JHP-MC (37) • PDJNR/L-PAD-JHP (38) • S-DDUNR/L (139) 198 ISCAR
