TURNING TOOLS OHX/OHN DCONMS 93º MG-SWUCR DMIN Solid Carbide Boring Bars GAMP GAMF Carrying WCGT Trigon Inserts for Small Diameters 93˚ WF LF Right hand tool shown Designation DCONMS LF OHN(1) OHX(2) WF GAMP(3) GAMF(4) DMIN MIID(5) MG 06-SWUCR-02 6.00 60.00 16.0 42.0 3.30 0.0 15.0 6.60 WCGT 0201 SR 14-299 T-6/5 MG 08-SWUCR-02 8.00 75.70 20.0 56.0 4.30 0.0 12.0 8.80 WCGT 0201 SR 14-299 T-6/5 (1) Minimum overhang in adjustment range (2) Maximum overhang in adjustment range (3) Rake angle axial (4) Rake angle radial (5) Master insert identification For inserts, see page: WCGT (264) For holders, see page: SC-PICCO (420) DMIN A-SXFOR/L GAMP GAMF 88º Boring Bars with Coolant HFB Holes Carrying XOMT Inserts DCONMS WF LDRED LF Right hand tool shown Designation DCONMS LF LDRED HFB WF GAMP(1) GAMF(2) DMIN MIID(3) A10J SXFOR/L-06 10.00 110.00 28.5 5.0 4.90 6.0 1.8 10.00 XOMT 0602 SR 34-508 M2.2X0.45 T-7/5 A12K SXFOR/L-06 12.00 125.00 28.5 5.0 4.90 6.0 1.8 10.00 XOMT 0602 SR 34-508 M2.2X0.45 T-7/5 (1) Rake angle axial (2) Rake angle radial (3) Master insert identification For inserts, see page: XOMT-DT (255) DCONMS HF A-SXFOR-DR GAMF H Boring and Drilling Bars GAMP with Coolant Holes Carrying XOMT Inserts WF LU LPR OAL=LF Right hand tool shown Designation DCONMS LF LPR LU WF HF GAMP(1) GAMF(2) H DCN(3) MIID(4) A1612M SXFOR-06DR 16.00 180.00 31.0 21.0 6.00 8.5 0.0 0.0 15.0 12.50 XOMT 06.. (1) Rake angle axial (2) Rake angle radial (3) Cutting diameter minimum (4) Master insert identification For inserts, see page: XOMT-DT (255) Drilling Solid Material Range: Dmin=12�5 mm D Dmax=14 mm To achieve required diameter øD, position tool as shown at D + x (x= 0�10) to compensate for tool deflection� D+x Use pecking cycle, pulling back 0�1 mm after each 1 mm of DOC� x Maximum feed for steel: 0�05 mm/rev; For stainless steel: 0.03 mm/rev Spare Parts Designation A-SXFOR-DR SR 34-508 M2.2X0.45 T-7/51 PL 16 157
