PARTING CW TAG N-MF RE 7° Single-Ended Inserts for Parting Grooving and Slitting Stainless and Alloy Steel at Medium Feed Recommended Dimensions Tough 1 Hard Machining Data f groove IC1030 IC1010 IC5400 IC830 IC808 IC807 Designation CW CWTOL(1) RE (mm/rev) TAG N2MF 2.00 0.050 0.20 • • • • • 0.04-0.15 TAG N3MF 3.05 0.050 0.20 • • • • • • 0.06-0.18 TAG N4MF 4.00 0.050 0.25 • • • • • 0.07-0.22 TAG N5MF 5.00 0.050 0.25 • • 0.08-0.25 • For cutting speed recommendations and user guide, see pages 606-615 (1) Cutting width tolerance (+/-) For tools, see pages: ADMP D45 (586) • TAGPAD-JHP (562) • TAGPAD-XL-JHP (562) • TAGPAD-Y-JHP (584) • TGAD (560) • TGAD RE/LE-JHP (560) • TGAQ (579) • TGAQ-ECD (JET-CROWN) (582) • TGAQ-JHP (578) • TGFH-JHP (555) • TGFH-MB (559) • TGFH-S (555) • TGFH/R/L (374) • TGFHL-TR (567) • TGFHR/L (556) • TGFHR/L-JHP (557) • TGFS (564) • TGSU (558) • TGTR/L-2T..SH-L120 (566) • TGTR/L-D (567) • TGTR/L-IQ (564) • TGTR/L-IQ-2Z (565) • TGTR/L-JHP (565) • TGTR/L-JHP-MC (566) JT J TAG N-J/JS/JT CW RE Single-Ended Inserts for 7º Parting, Grooving and Slitting Soft Materials Recommended Dimensions Tough 1 Hard Machining Data f groove IC1030 IC1010 IC5400 IC830 IC928 IC808 IC908 IC807 Designation CW RE CWTOL(2) RETOL(3) IC20 (mm/rev) TAG N1.4J 1.40 0.16 0.040 0.030 • • • 0.03-0.10 TAG N1.6J 1.60 0.16 0.040 0.030 • • 0.03-0.12 TAG N2JS (1) 2.00 0.02 0.040 0.020 • • 0.03-0.08 TAG N2J 2.00 0.20 0.040 0.040 • • • • • • 0.04-0.12 TAG N2JT 2.00 0.20 0.040 0.040 • • • • • • 0.04-0.14 TAG N3JS (1) 3.05 0.02 0.040 0.020 • • 0.04-0.10 TAG N3J 3.05 0.20 0.040 0.030 • • • • • • • • • 0.04-0.16 TAG N3JT 3.05 0.20 0.040 0.030 • • • • 0.05-0.18 TAG N3.2JT 3.25 0.20 0.040 0.030 • • 0.05-0.18 TAG N4J 4.00 0.24 0.040 0.030 • • • • • • • • 0.04-0.18 TAG N4JT 4.05 0.24 0.040 0.030 • • • • 0.06-0.20 TAG N5J 5.05 0.25 0.040 0.040 • • • 0.05-0.20 TAG N5JT 5.05 0.25 0.040 0.040 • • • 0.06-0.22 TAG N6.3J 6.35 0.34 0.040 0.040 • • 0.06-0.22 TAG N6.3JT 6.35 0.34 0.040 0.040 • • 0.08-0.25 TAG N7JT 7.05 0.50 0.040 0.040 • • 0.10-0.28 • JT chipformer has the basic positive configuration of the J-type and a reinforced negative front edge; most suitable for soft materials at low to medium feeds. • For cutting speed recommendations and user guide, see pages 606-615 (1) Sharp corners cannot be used on TGSF slitting cutters (2) Cutting width tolerance (+/-) (3) Corner radius tolerance (+/-) For tools, see pages: ADMP D45 (586) • TAGPAD-JHP (562) • TAGPAD-XL-JHP (562) • TAGPAD-Y-JHP (584) • TGAD (560) • TGAD RE/LE-JHP (560) • TGAQ (579) • TGAQ-ECD (JET-CROWN) (582) • TGAQ-JHP (578) • TGBHR/L (372) • TGFH-JHP (555) • TGFH-MB (559) • TGFH-S (555) • TGFH/R/L (374) • TGFHL-TR (567) • TGFHR/L (556) • TGFHR/L-JHP (557) • TGFS (564) • TGSU (558) • TGTR/L-2T..SH-L120 (566) • TGTR/L-D (567) • TGTR/L-IQ (564) • TGTR/L-IQ-2Z (565) • TGTR/L-JHP (565) • TGTR/L-JHP-MC (566) 570 ISCAR
