TURNING INSERTS 55° 60° 93º-95º MAX DNMG-CERMET 62.5º 30º MAX Double-Sided 55° Rhombic 27° IC MAX Cermet Grade Inserts 93° for Semi-Finishing and Finishing Applications RE L S Dimensions Tough 1 Hard Recommended Machining Data IC520N IC20N ap f Designation L IC S RE (mm) (mm/rev) DNMG 110402-FFC 11.63 9.52 4.76 0.20 • 0.40-2.50 0.05-0.20 DNMG 110404-FFC 11.63 9.52 4.76 0.40 • 0.80-3.00 0.07-0.25 DNMG 110404-FFG 11.63 9.52 4.76 0.40 • 0.70-2.00 0.07-0.22 DNMG 110408-FFC 11.63 9.52 4.76 0.80 • • 1.00-3.50 0.08-0.25 DNMG 150404-FFC 15.50 12.70 4.76 0.40 • 0.80-3.00 0.07-0.25 DNMG 150604-FB 15.50 12.70 6.35 0.40 • 0.50-3.00 0.07-0.23 DNMG 150604-FFC 15.50 12.70 6.35 0.40 • 0.80-3.00 0.08-0.25 • For user guide and cutting speed recommendations, see pages 160-170, 274-278 For tools, see pages: A/S-PDUNR/L (140) • C#-DDJNR/L (40) • C#-PDJNR/L-JHP (38) • DDJNR/L (39) • HSK A63WH-DDJNR/L (40) • HSK A63WH-DDNNN (41) • PDJNR/L (36) • PDJNR/L-JHP (37) • PDJNR/L-JHP-MC (37) • PDJNR/L-PAD-JHP (38) • S-DDUNR/L (139) • DDJNR/L-JHP-MC (39) D.O.C (mm) 4 FB FFC FFG 0 0.4 Feed (mm/rev) 55° 60° 27° MAX MAX DNMG/DNGG-SF 62.5º 93° Double-Sided 55° Rhombic IC 93º-95º Inserts for Super Finishing; Controls Chip Flow at Very Low 30º MAX Feeds and Depths of Cut RE L S Dimensions Tough 1 Hard Recommended Machining Data IC530N IC520N ap f IC907 Designation L IC S RE (mm) (mm/rev) DNMG 110404-SF 11.63 9.52 4.76 0.40 • • 0.50-3.00 0.05-0.25 DNGG 150401-SF 15.50 12.70 4.76 0.10 • 0.25-2.00 0.03-0.15 DNGG 150402-SF 15.50 12.70 4.76 0.20 • 0.40-2.50 0.05-0.20 • For user guide and cutting speed recommendations, see pages 160-170, 274-278 For tools, see pages: A/S-PDUNR/L (140) • C#-DDJNR/L (40) • C#-PDJNR/L-JHP (38) • DDJNR/L (39) • HSK A63WH-DDJNR/L (40) • HSK A63WH-DDNNN (41) • PDJNR/L (36) • PDJNR/L-JHP (37) • PDJNR/L-JHP-MC (37) • PDJNR/L-PAD-JHP (38) • AVC-DDUNR/L (126) • DDJNR/L-JHP-MC (39) 199
