TURNING TOOLS DMIN HF 95º A/S-MWLNR/L-W Top Wedge Lock Boring HFB Bars Carrying Double- H Sided Trigon Inserts WF LDRED LF DCONMS Right hand tool shown Designation DCONMS LF LDRED H HFB WF DMIN HF CSP(2) MIID(3) A20Q MWLNR/L-06W 20.00 180.00 28.0 18.0 9.2 13.00 25.00 0.2 1 WNMG 06T3 A20 MWLNR/L-06W-AD (1) 20.00 100.00 28.0 18.0 9.0 13.00 25.00 0.0 1 WNMG 06T3 A25R MWLNR/L-06W 25.00 200.00 34.0 23.0 11.7 17.00 32.00 0.2 1 WNMG 06T3 A32S MWLNR/L-06W 32.00 250.00 28.0 29.0 14.7 19.00 36.00 0.2 1 WNMG 06T3 S20S MWLNR/L-06W 20.00 250.00 28.0 18.0 9.2 13.00 25.00 0.2 0 WNMG 06T3 S25T MWLNR/L-06W 25.00 300.00 28.0 23.0 11.7 17.00 32.00 0.2 0 WNMG 06T3 S32U MWLNL-06W 32.00 350.00 40.0 29.0 14.7 19.00 36.00 0.2 0 WNMG 06T3 S32U MWLNR-06W 32.00 350.00 28.0 29.0 14.7 19.00 36.00 0.2 0 WNMG 06T3 A25R MWLNR/L-08W 25.00 200.00 40.0 23.0 11.7 17.00 32.00 0.2 1 WNMG 0804 A25 MWLNR-08W-AD (1) 25.00 120.00 35.0 23.0 11.7 17.00 32.00 0.2 1 WNMG 0804 A32S MWLNR/L-08W 32.00 250.00 45.0 29.0 14.7 22.00 40.00 0.2 1 WNMG 0804 A40T MWLNR/L-08W 40.00 300.00 50.0 36.0 18.2 27.00 50.00 0.2 1 WNMG 0804 S25T MWLNR/L-08W 25.00 300.00 35.0 23.0 11.7 17.00 32.00 0.2 0 WNMG 0804 S32U MWLNR/L-08W 32.00 350.00 45.0 28.0 14.7 22.00 40.00 0.7 0 WNMG 0804 S40V MWLNR/L-08W 40.00 400.00 50.0 36.0 18.2 27.00 50.00 0.2 0 WNMG 0804 S50V MWLNL-13W 50.00 400.00 63.0 47.0 23.5 35.00 63.00 0.0 0 WNMG 1306 S50V MWLNR-13W 50.00 400.00 63.0 47.0 23.5 35.00 63.00 0.2 0 WNMG 1306 (1) AD - short tool for adapter holders (2) 0 - Without coolant supply, 1 - With coolant supply (3) Master insert identification For inserts, see pages: WNMG-F3P (172) • WNMG-M3P (173) • WNMG-F3S (176) • WNMG-F3M (175) • WNMG-M3M (175) • WNMM-NM (179) • WNMG-TF (178) • WNMG-GN (179) • WNMG-NR (179) • WNMG-PP (178) • WNMG-VL (177) • WNMG-TNM (180) • WNMG-SF (176) • WNMG-NF (176) • WNMG-WF (177) • WNMA/WNMA-WG (180) • WNMG-WG (177) • WNMG-CERMET (173) • WNGG-F3N (266) Spare Parts Designation A20 MWLNR/L-06W-AD ZNW 3WI LC 250 SET 1 HW 2.5 PL 20 A20Q MWLNR/L-06W ZNW 3WI LC 250 SET 1 HW 2.5 PL 20 A25R MWLNR/L-06W IWSN 322W IWSN 3-2W* ZNW 3W LC 250 SET 1 HW 2.5 PL 25 A32S MWLNR/L-06W IWSN 322W IWSN 3-2W* ZNW 3W LC 250 SET 1 HW 2.5 PL 32 S20S MWLNR/L-06W ZNW 3WI LC 250 SET 1 HW 2.5 S25T MWLNR/L-06W IWSN 322W IWSN 3-2W* ZNW 3W LC 250 SET 1 HW 2.5 S32U MWLNR/L-06W IWSN 322W IWSN 3-2W* ZNW 3W LC 250 SET 1 HW 2.5 A25R MWLNR/L-08W TWN 423 ZNW-4WI LC 252 SET 2 HW 3.0 PL 25 A25 MWLNR-08W-AD TWN 423 ZNW-4WI LC 252 SET 2 HW 3.0 PL 25 A32S MWLNR/L-08W TWN 423 ZNW-4WI LC 252 SET 1 HW 3.0 PL 32 A40T MWLNR/L-08W IWSN 433 IWSN 433M* ZNW 4W LC 252 SET 1 HW 3.0 PL 40 S25T MWLNR/L-08W TWN 423 ZNW-4WI LC 252 SET 2 HW 3.0 S32U MWLNR/L-08W TWN 423 ZNW-4WI LC 252 SET 1 HW 3.0 S40V MWLNR/L-08W IWSN 433 IWSN 433M* ZNW 4W LC 252 SET 1 HW 3.0 S50V MWLNR/L-13W IWSN 635 ZNW 6W LC 253 SPR 17-362 WA M8 SR 17-362 HW 4P * Optional, to be ordered separately 136 ISCAR
