TOOLS FOR ALUMINUM WHEELS ±0.025 30 Ref. GIPA/GIDA 8 (full radius) Precision Double-Ended 10° 7° 6.4 Inserts with Polished Top Rake GIDA 80-40CB CW GIDA 80-40 for Machining Aluminum RE BW GIPA 8.00-4.00 Dimensions Tough 1 Hard Recommended Machining Data ap f turn f groove IC1520 IC20 IC4 ID5 Designation CW RE CWTOL(2) RETOL(3) BW (mm) (mm/rev) (mm/rev) GIDA 80-40 8.00 4.00 0.020 0.050 5.60 • • • 0.00-4.00 0.24-0.67 0.14-0.38 GIDA 80-40-D 8.00 4.00 0.020 0.050 5.60 • 0.00-4.00 0.24-0.67 0.14-0.38 GIDA 80-40CB-D (1) 8.00 4.00 0.020 0.050 5.60 • 0.00-4.00 0.24-0.67 0.14-0.38 GIDA 80-40YZ 8.00 4.00 0.020 0.050 5.60 • • • 0.00-4.00 0.24-0.67 0.14-0.38 GIDA 80-40YZ-D 8.00 4.00 0.020 0.050 5.60 • 0.00-4.00 0.35-0.96 0.18-0.48 GIPA 8.00-4.00 8.00 4.00 0.020 0.050 6.00 • • 0.00-4.00 0.24-0.67 0.14-0.38 • ID5 is a single-ended PCD tipped insert • For cutting speed recommendations and user guide, see pages 606-615 (1) Should not be clamped on tools with “A” suffix (2) Cutting width tolerance (+/-) (3) Corner radius tolerance (+/-) For tools, see pages: C#-GHDR/L (301) • CGHN-8-10D (315) • GADR/L-8 (314) • GADR/L-JHP (315) • GAFG-R/L-8 (661) • GHDKR/L (503) • GHDR/L (long pocket) (313) • GHDR/L-8A (503) • GHDR/L-JHP (long pocket) (313) • GHFGR/L-8 (659) • GHIFR/L-A (503) • GHIR/L (W=7.0-8.3) (398) • GHIUR/L-C-A (15° & 27.5°) Bars (502) • GHIUR/L-UC (502) ±0.025 GIPA 8-35V (V-shape) 30 Ref. V-Shaped Inserts for Machining Aluminum Wheels 7° 6.4 35° RE BW Dimensions Tough 1 Hard Recommended Machining Data ap f turn IC1520 IC20 IC4 ID5 Designation RE RETOL(2) BW (mm) (mm/rev) GIPA 6.0-35V-0.8 0.80 0.050 4.80 • 1.00-3.60 0.21-0.48 GIPA 8YZ-35V-0.80 0.80 0.050 6.00 • 1.00-4.80 0.24-0.56 GIPA 8YZ-35V-1.20-D (1) 1.20 0.050 6.00 • 1.45-4.80 0.35-0.88 GIPA 8-35V-1.20 1.20 0.050 6.00 • • 1.45-4.80 0.24-0.62 GIPA 8-35V-1.20-D (1) 1.20 0.050 6.00 • 1.45-4.80 0.35-0.88 GIPA 8-35V-3.0 3.00 0.050 6.00 • 3.60-4.80 0.24-0.67 • Precision ground and polished rake to avoid built-up edge • Toolholder seat needs to be modified according to insert profile to ensure clearance (1) Single-ended PCD tipped insert (2) Corner radius tolerance (+/-) For tools, see pages: GHIUR/L-C-22.5A-8V (502) • GHIUR/L-C-A (15° & 27.5°) Bars (502) • GHIUR/L-UC (502) • GHVR/L (503) 505
