PARTING TGSU ...-4Z TGSU OAL CWN-CWX Parting and Grooving Flat Top 1 3 1 Blades with Tangential Pockets 30 40 50 60 MAX. CUTDIA HF H Carrying TANG-GRIP MAX. 60 50 40 30 2 4 2 Single-Ended Inserts WB 150° Designation H CWN(2) CWX(3) CUTDIA(4) NOP(5) WB OAL HF CSP(6) Insert TGSU 35-1.4-IQ 35.0 1.40 1.40 35.0 2 2.50 (7) 180.00 33.2 0 TAG 1.4 ETG 1.4/1.6* TGSU 35-2-IQ 35.0 1.80 2.40 59.5 2 2.50 (8) 160.00 33.2 0 TAG 2 ETG 2* TGSU 35-3-IQ-4Z 35.0 2.80 3.50 120.0 4 2.50 180.00 33.2 0 TAG 3 ETG 3-4-SH* TGSU 35-4-IQ-4Z 35.0 3.70 4.50 120.0 4 3.40 180.00 33.2 0 TAG 4 ETG 3-4-SH* TGSU 35-5-IQ 35.0 4.70 5.50 144.0 2 4.00 180.00 33.2 0 TAG 5 ETG 5-7* TGSU 35-6-IQ 35.0 5.70 6.50 144.0 2 5.20 180.00 33.2 0 TAG 6 ETG 5-7* TGSU 35-7-IQ 35.0 6.80 7.50 144.0 2 6.00 180.00 33.2 0 TAG 7 ETG 5-7* TGSU 35C-8-IQ (1) 35.0 7.70 8.50 144.0 2 7.20 180.00 33.2 1 TAG 8 ETG 8-12* TGSU 35C-9-IQ (1) 35.0 8.70 10.00 144.0 2 8.20 180.00 33.2 1 TAG 9 ETG 8-12* TGSU 56C-7-IQ (1) 56.0 6.80 7.50 220.0 2 6.00 260.00 53.6 1 TAG 7 ETG 5-7* TGSU 56C-8-IQ (1) 56.0 7.70 8.50 220.0 2 7.20 260.00 53.6 1 TAG 8 ETG 8-12* TGSU 56C-9-IQ (1) 56.0 8.70 10.00 220.0 2 8.20 260.00 53.6 1 TAG 9 ETG 8-12* • For user guide, see pages 606-615 (1) C- Internal coolant, use with TGTBU HD blocks only; cooling tube SGCU 341 should be ordered separately (2) Minimum cutting width (3) Maximum cutting width (4) Maximum workpiece diameter for grooving operation (5) Number of pockets (6) 0 - Without coolant supply, 1 - With coolant supply (7) Thickness at the D.O.C. area is 1.05 mm (8) Thickness at the D.O.C. area is 1.65 mm * Optional, to be ordered separately For inserts, see pages: TAG N-A (573) • TAG N-C (full radius) (569) • TAG N-C/W/M (568) • TAG N-HF (568) • TAG N-J/JS/JT (570) • TAG N-LF (572) • TAG N-MF (570) • TAG N-T (573) • TAG N-UT (572) • TAG R/L-C (569) • TAG R/L-J/JS (571) • TAGB/TAGBA (375) For holders, see pages: TGTBU (558) TGSU 35-3-IQ-4Z 1 3 TGSU 35-4-IQ-4Z 2 4 TGTBU Tool Blocks for TGSU Parting WTHPRM OAH H HTPRM and Grooving Blades HBH B OAL OAW Choose blade by HTPRM dimension Designation H B HTPRM WTHPRM OAW OAH HBH OAL TGTBU 20-35 20.0 19.0 35.00 6.00 38.00 56.0 23.7 110.00 BKU 110 SR M6X16 DIN912 HW 5.0 TGTBU 25-35 25.0 23.0 35.00 6.00 42.00 56.0 18.7 110.00 BKU 110 SR M6X16 DIN912 HW 5.0 TGTBU 32-35 32.0 29.0 35.00 6.00 48.00 56.0 11.7 110.00 BKU 110 SR M6X16 DIN912 HW 5.0 TGTBU 32-35 HD (1) 32.0 30.0 35.00 8.00 55.00 64.0 18.0 130.00 BK 509 SR M8X20DIN912 HW 6.0 TGTBU 40-35 40.0 41.0 35.00 6.00 60.00 56.0 3.7 110.00 BKU 110 SR M6X16 DIN912 HW 5.0 TGTBU 40-35 HD (1) 40.0 41.0 35.00 8.00 66.00 64.0 10.0 130.00 BK 509 SR M8X20DIN912 HW 6.0 TGTBU 40-56 HD (1) 40.0 41.0 56.00 8.00 66.00 72.0 28.0 130.00 BK 509 SR M8X20DIN912 HW 6.0 (1) HD - recommended blocks for TGSU...-8, TGSU...-9 blades For tools, see pages: TGSU (558) 558 ISCAR
