FACE GROOVING OAL PICCO-015 (Face Grooving) CDX DCONMS Inserts for Deep Face Grooving DAXN a CW CW OHN Right-hand shown Recommended Dimensions Machining Data f face-groove IC228 Designation DAXN(1) CW CDX DCONMS OHN(2) OAL a (mm/rev) PICCO R/L 015.3015-20 15.0 3.00 19.00 7.00 20.0 35.00 5.90 • 0.02-0.05 PICCO R 015.2515-20 15.0 2.50 19.00 7.00 20.0 35.00 5.90 • 0.01-0.04 PICCO R 015.3015-30 15.0 3.00 29.00 7.00 30.0 45.00 5.90 • 0.01-0.04 • Only right-hand inserts are available as standard, left-hand inserts on request • All inserts are with sharp corners • For detailed cutting data, see page 678 (1) Minimum axial grooving diameter (2) Minimum overhang KITS KIT PICCO Face Contains One Toolholder and a Set of Solid Carbide DAXN Miniature Face Turning and Grooving Boring Bars CWN-CWX Designation DAXN(1) CWN(2) CWX(3) KIT PICCO SET-4R 8.0 1.00 3.00 (1) Minimum axial grooving diameter (2) Minimum cutting width (3) Maximum cutting width PICCO Face Grooving PICCO Mini-Bar Tool Set - 4R Mini Bore Designation Dia. OHN CDX CW Pcs. Designation CDX PICCO 16.D6 1x Holder Min Bore PICCO R/L 010.1008-10 8�0 11 1�5 1�0 1x Mini Carbide Bar Dia. PICCO R/L 010.1508-10 8�0 11 2�5 1�5 1x Mini Carbide Bar CW PICCO R/L 010.2008-10 8�0 11 3�0 2�0 1x Mini Carbide Bar OHN PICCO R/L 010.2508-20 8�0 21 3�5 2�5 1x Mini Carbide Bar PICCO R/L 010.3008-20 8�0 21 3�5 3�0 1x Mini Carbide Bar Available grade: IC228 OHX MGCH-C (face) Face Machining Tools Carrying GFQR Inserts for Dmin 12 - MGCH 09C DCONMS (MG PCO-16-9) Dmax 19 mm Penetration Range WF OAL The same tool applies for right-and left-machining Designation DCONMS OAL OHX(1) WF MGCH 09C 9.00 83.50 65.0 5.50 SR 76-2145 T-15/5 (1) Maximum overhang For inserts, see pages: GFQR (633) For holders, see pages: PICCO/MG PCO (Holder) (441) MG PCO 75 Holder Bar for Adjustable Shank 15 16 MG PCO-16-9 632 ISCAR
