TURNING INSERTS 55° 60° 27° MAX MAX DNMG/DNGG-PP 62.5º 93° 55° Double-Sided Rhombic IC 93º-95º Inserts for Machining Very Ductile Materials under 30º MAX Medium Cutting Conditions RE L S Recommended Dimensions Tough 1 Hard Machining Data IC8350 IC6025 IC8250 IC6015 IC8150 ap f IC830 IC806 IC807 IC907 IC804 IC10 IC20 Designation L IC S RE (mm) (mm/rev) DNMG 110404-PP 11.63 9.52 4.76 0.40 • • 0.40-3.00 0.12-0.30 DNMG 110408-PP 11.63 9.52 4.76 0.80 • • • • 1.00-3.50 0.12-0.30 DNMG 150408-PP 15.50 12.70 4.76 0.80 • • • 1.00-4.00 0.12-0.30 DNMG 150604-PP 15.50 12.70 6.35 0.40 • • 0.50-4.00 0.12-0.30 DNMG 150608-PP 15.50 12.70 6.35 0.80 • • • • • • • • 1.00-3.50 0.12-0.30 DNGG 150604-PP 15.50 12.70 6.35 0.40 • 0.50-4.00 0.12-0.30 DNGG 150608-PP 15.50 12.70 6.35 0.80 • • • 1.00-4.00 0.12-0.30 • For user guide and cutting speed recommendations, see pages 160-170, 274-278 For tools, see pages: A/S-PDUNR/L (140) • AVC-DDUNR/L (126) • AVC-DDUNR/L-VH (128) • C#-DDJNR/L (40) • C#-PDJNR/L-JHP (38) • DDJNR/L (39) • HSK A63WH-DDJNR/L (40) • HSK A63WH-DDNNN (41) • PDJNR/L (36) • PDJNR/L-JHP (37) • PDJNR/L-JHP-MC (37) • PDJNR/L-PAD-JHP (38) • S-DDUNR/L (139) • DDJNR/L-JHP-MC (39) 55° 60° 93º-95º MAX DNMG-VL 62.5º 30º MAX Double-Sided 55° Rhombic 27° IC MAX Inserts with a Chipformer 93° for High Temperature Alloys and Stainless Steel Valves RE L S Dimensions Tough 1 Hard Recommended Machining Data ap f IC1017 IC908 IC806 Designation L IC S RE (mm) (mm/rev) DNMG 110404-VL 11.63 9.52 4.76 0.40 • • • 0.50-3.50 0.10-0.25 DNMG 110408-VL 11.63 9.52 4.76 0.80 • • 0.50-3.50 0.10-0.25 DNMG 150404-VL 15.50 12.70 4.76 0.40 • 0.50-3.50 0.10-0.25 DNMG 150408-VL 15.50 12.70 4.76 0.80 • • 0.50-3.50 0.10-0.25 • For user guide and cutting speed recommendations, see pages 160-170, 274-278 For tools, see pages: A/S-PDUNR/L (140) • C#-DDJNR/L (40) • C#-PDJNR/L-JHP (38) • DDJNR/L (39) • HSK A63WH-DDJNR/L (40) • HSK A63WH-DDNNN (41) • PDJNR/L (36) • PDJNR/L-JHP (37) • PDJNR/L-JHP-MC (37) • PDJNR/L-PAD-JHP (38) • S-DDUNR/L (139) • AVC-DDUNR/L (126) • DDJNR/L-JHP-MC (39) 201
