TOOLS FOR MINIATURE PARTS OAL PICCO ISO Full Profile DCONMS X ISO Standard Inserts for 6H Full Profile Threads OHN PDX PDX DIN13, ISO 68-1, ISO 965 (1&2) 60° a WF HC WB CF X Right-hand shown NUT 1/4 TP Dimensions 60° 1/8 TP SCREW IC908 Designation DCONMS DMIN HC CF PDX WF a WB OHN(1) OAL TP(2) PICCO R/L 105.0510-15 5.00 4.80 0.54 0.12 0.60 1.90 4.40 3.30 15.0 30.00 1.000 • PICCO R/L 106.0612-15 6.00 6.00 0.67 0.15 0.70 2.30 5.30 3.40 15.0 30.00 1.250 • PICCO R/L 106.0815-15 6.00 6.00 0.81 0.18 0.80 2.30 5.30 3.40 15.0 30.00 1.500 • PICCO R/L 107.0815-15 7.00 7.00 0.81 0.18 0.80 2.80 6.30 3.80 15.0 30.00 1.500 • (1) Minimum overhang (2) Thread pitch For holders, see pages: PICCO ACE (440) • PICCO/MG PCO (Holder) (441) • SC-PICCO (442) OAL PICCO ISO Full Profile Fine DCONMS X ISO Fine Pitch Inserts for 6H OHN PDX Full Profile Threads PDX DIN13, ISO 68-1, ISO 965 (1&2) 60° a WF HC X WB CF Right-hand shown NUT 1/4 TP Dimensions 60° 1/8 TP SCREW IC908 Designation DCONMS DMIN HC CF PDX WF a OHN(1) WB OAL TP(2) PICCO R/L 104.0205-15 5.00 4.00 0.27 0.06 0.40 1.50 3.50 15.0 2.40 30.00 0.500 • PICCO R/L 105.0205-15 5.00 5.00 0.27 0.06 0.40 1.90 4.40 15.0 3.30 30.00 0.500 • PICCO R/L 105.0407-15 5.00 5.00 0.40 0.09 0.50 1.90 4.40 15.0 3.30 30.00 0.750 • PICCO R/L 106.0510-15 6.00 6.00 0.54 0.12 0.60 2.30 5.30 15.0 3.40 30.00 1.000 • (1) Minimum overhang (2) Thread pitch For holders, see pages: PICCO ACE (440) • PICCO/MG PCO (Holder) (441) • SC-PICCO (442) KITS Fig. A Fig. B Fig. C KIT PICCO SET Contains 2 Toolholders and a Set of Solid Carbide Miniature Turning DMIN and Grooving Boring Bars Designation DMIN Qty KIT PICCO SET-1R 3.00 12 Designation DMIN OHN CDX CW OAL Pcs. Fig. Description PICCO ACE 16-4 — — — — 85 1 — Holder PICCO ACE 16-6 — — — — 85 1 — Holder PICCO R 080.0004-25 4�0 24�0 0�80 1�5 39 1 A Mini carbide bar PICCO R 003.0070-16 3�0 15�0 0�60 0�7 29 1 C Mini carbide bar PICCO RM050.2-10 2�0 10�0 0�08 — 24 1 A Mini carbide bar PICCO R 050.1-5 1�0 4�5 0�10 — 20 1 A Mini carbide bar PICCO R 003.0070-5 3�0 5�0 0�60 0�7 19 1 C Mini carbide bar PICCO R 006.1.00-25 6�0 24�0 1�80 2�0 40 1 A Mini carbide bar PICCO R 006.0100-22 6�0 21�0 1�80 1�0 37 1 C Mini carbide bar PICCO R 050.6-15 6�0 14�0 0�50 — 30 1 A Mini carbide bar PICCO RX050.6-15R10 6�0 15�0 0�40 — 30 1 A Mini carbide bar PICCO R 006.0510-15 6�0 15�0 — — 30 1 B Mini carbide bar 463
