PARTING CUTDIA OAL D/HGAD RE/LE-JHP Parting and Grooving OAH Adapters with Channels HF for High-Pressure Coolant WF Bar Max LF Carrying DO-GRIP Inserts CW WB WB_2 Designation CWN(2) CWX(3) WF WB WB_2 LF OAL OAH HF CUTDIA Insert DGAD 2R/LE-D38-JHP (1) 1.90 2.50 4.50 1.60 5.3 40.40 54.35 25.80 18.9 38.0 DGN 2 EDG 33A* DGAD 3R/LE-D38-JHP (1) 3.00 3.18 4.08 2.45 5.3 40.40 54.35 25.80 18.9 38.0 DGN 3 EDG 33A* HGAD 3R/LE-D42-JHP 3.00 3.00 4.08 2.45 5.3 38.40 52.35 25.80 18.9 42.0 HGN 3/GRIP 3 EDG 23B* • For user guide, see pages 606-615 (1) For parting and external grooving only (2) Minimum cutting width (3) Maximum cutting width * Optional, to be ordered separately For inserts, see pages: DGN-LF/LFT (546) • DGN-MF (541) • DGN-P (548) • DGN-UT/UA (547) • DGN-WP (549) • DGN-Z (546) • DGN/DGNC/DGNM-C (539) • DGN/DGNM-J/JS/JT (544) • DGR-P (548) • DGR-WP (549) • DGR-Z/ZS (547) • DGR/L-C DGRC/LC-C (540) • DGR/L-J/JS (545) • GRIP (294) • GRIP (full radius) (295) • GRIP-T (295) • GRIPA (296) • GRIPA (full radius) (296) • HGN-C (549) • HGN-J (550) • HGN-UT (551) • HGR/L-C (550) • HGR/L-J/JS (550) For holders, see pages: NMAHR/L-JHP (560) OAL PCAD RE/LE-JHP OAH Bar Max Parting and Grooving HF Adapters with Channels LF for High-Pressure Coolant WB_2 Carrying PENTA 24 Inserts WF CW WB Right-hand shown Designation CWN(1) CWX(2) WF WB WB_2 LF OAL OAH HF Insert PCAD 24R/LE-JHP 0.50 3.18 5.20 11.00 5.3 41.40 55.30 25.80 18.9 PENTA 24 • For user guide, see pages 606-615 (1) Minimum cutting width (2) Maximum cutting width For inserts, see pages: PENTA 24-BSPT (767) • PENTA 24-ISO (742) • PENTA 24-MT (725) • PENTA 24-NPT (763) • PENTA 24-UN (753) • PENTA 24-W (759) • PENTA 24-WT (717) • PENTA 24N-C (359) • PENTA 24N-C (full radius) (360) • PENTA 24N-C-SL (356) • PENTA 24N-J (358) • PENTA 24N-J (full radius) (359) • PENTA 24N-J-SL (356) • PENTA 24N-PF (full radius) (361) • PENTA 24N-PF/P (360) • PENTA 24N-Z (361) • PENTA 24R-C (601) • PENTA 24R-P (602) • PENTA 24R/L-DSL (357) • PENTA 24R/L-J (598) • PENTA 24R/L-Z (600) For holders, see pages: NMAHR/L-JHP (560) Spare Parts Designation PCAD 24LE-JHP SR 16-212-01397L PCAD 24RE-JHP SR 16-212-01397 561
