TURNING TOOLS 60° MAX HF NQCH-SDNCN-S-JHP 62.5º Screw Lock JETCUT Modular holder Heads Carrying 7° Clearance WF 55° Rhombic Inserts for Swiss-Type Machines 62.5º LH OAL Designation WF HF LH OAL MIID(1) NQCH12R/L-SDNCN-11S-JHP 6.00 12.0 21.0 28.80 DC..11T3.. NQCH16R/L-SDNCN-11S-JHP 8.00 16.0 21.0 28.80 DC..11T3.. New • Use only RH Shank with RH Head and LH Shank with LH Head (1) Master insert identification For inserts, see pages: DCGT-AF (271) • DCGT-AS (270) • DCGT-F1M-12P (243) • DCGT-F1M-20P (244) • DCMT-14 (247) • DCMT-CERMET (243) • DCMT-F3P (240) • DCMT-M3M (241) • DCMT-M3P (241) • DCMT/DCGT (246) • DCMT/DCGT-PF (245) • DCMT/DCGT-SM (246) For holders, see page: NQCH-JHP (424) Spare Parts Designation NQCH-SDNCN-S-JHP SR 16-236 P T-15/5 60° MAX C#-SDNCN 62.5º 70 Bar Max Screw Lock Tools with CAMFIX Exchangeable Shanks Carrying 55° Rhombic Inserts DCONMS with 7° Clearance Angle LF Designation DCONMS LF MIID(1) CP(2) DCP(3) C4 SDNCN-00050-11 40.00 50.00 DC.. 11T3 70 1 TDC 3-1P SR TC-3P HW 4.0 SR 16-236 P T-15/5 EZ 104 (1) Master insert identification (2) Coolant pressure (Bar) (3) 1 - Slot for data chip, 0 - Without slot for data chip For inserts, see pages: DCGT-F1M-12P (243) • DCGT-F1M-20P (244) • DCMT-CERMET (243) • DCMT-F3P (240) • DCMT-M3P (241) • DCMT-M3M (241) • DCMT/DCGT-PF (245) • DCMT/DCGT-SM (246) • DCGT-AS (270) • DCGT-AF (271) • DCMT-14 (247) • DCMT/DCGT (246) HF H PVACR/L-S 52º 91° MAX Side Lever Lock Tools Carrying 35° Positive Rhombic Inserts WF B for Swiss Automatic Machines LF Right hand tool shown Designation H HF B LF WF MIID(1) PVACR/L 0808M-11S 8.0 8.0 8.0 150.00 8.00 VC..1103 SL LV-2 SL PI-2 PIN SR 10400611 HW 2.0/5 PVACR/L 1010M-11S 10.0 10.0 10.0 150.00 10.20 VC..1103 SL LV-2 SL PI-2 PIN SR 10400611 HW 2.0/5 PVACR/L 1212M-11S 12.0 12.0 12.0 150.00 12.20 VC..1103 SL LV-2 SL PI-2 PIN SR 10400611 HW 2.0/5 PVACR/L 1616M-11S 16.0 16.0 16.0 150.00 16.20 VC..1103 SL LV-2 SL PI-2 PIN SR 10400611 HW 2.0/5 PVACR 2020K-11S 20.0 20.0 20.0 125.00 20.20 VC..1103 SL LV-2 SL PI-2 PIN SR 10400611 HW 2.0/5 • The clamping screw may by transferred to the opposite side if needed (1) Master insert identification For inserts, see pages: VCGT-F1M-12P (250) • VCGT-F1M-20P (250) • VCMT-F3P (248) • VCMT-M3P (248) • VCMT-F3M (249) • VCMT-SM (251) • VCET-WF (251) • VCGT-AS (269) 84 ISCAR
