Токарные инструменты Iscar (часть 1) 2026 - страница 91

TURNING TOOLS NQCH-SVACR/L-S-JHP 52º HF 91° MAX Screw Lock JETCUT Modular Holder OAW Heads Carrying 35° Rhombic Inserts with 7° Clearance Angle Bar Max WF for Swiss-Type Machines 91˚ LH OAL Right hand tool shown Designation WF HF LH OAL OAW MIID(1) NQCH12-SVACR/L-11S-JHP 12.15 12.0 20.0 28.80 20.15 VC.. 1103.. SR 14-560 T-8/5 NQCH16-SVACR/L-11S-JHP 16.15 16.0 20.0 28.80 20.15 VC.. 1103.. SR 14-560 T-8/5 • Use only RH Shank with RH Head and LH Shank with LH Head (1) Master insert identification For inserts, see pages: VCET-WF (251) • VCGT-AS (269) • VCGT-F1M-12P (250) • VCGT-F1M-20P (250) • VCGT-MD/PF (251) • VCMT-F3M (249) • VCMT-F3P (248) • VCMT-M3P (248) • VCMT-SM (251) For holders, see page: NQCH-JHP (424) GAMP GAMF PVACR/L-S-JHP HF H 91° 52º MAX Tools with Channels for High HBKW Pressure Coolant Carrying 35° UNF 5/16”-24 typx3 Positive Rhombic Inserts for WF B Bar Max Swiss Automatic Machines 91° LH LF Right hand tool shown Designation H HF B LF LH WF HBKW GAMP(1) GAMF(2) MIID(3) PVACR 1010H-11S-JHP 10.0 10.0 10.0 100.00 20.0 10.20 5.80 0.0 0.0 VC..1103 PVACR/L 1212H-11S-JHP 12.0 12.0 12.0 100.00 20.0 12.20 3.80 0.0 0.0 VC..1103 PVACR/L 1616K-11S-JHP 16.0 16.0 16.0 125.00 20.0 16.20 - 0.0 0.0 VC..1103 PVACR/L 2020K-11S-JHP 20.0 20.0 20.0 125.00 25.0 20.20 - 0.0 0.0 VC..1103 • For user guide, see pages 6-7,104-110 (1) Rake angle axial (2) Rake angle radial (3) Master insert identification For inserts, see pages: VCGT-F1M-12P (250) • VCGT-F1M-20P (250) • VCMT-F3P (248) • VCMT-M3P (248) • VCMT-F3M (249) • VCMT-SM (251) • VCET-WF (251) • VCGT-AS (269) Spare Parts Designation PVACR 1010H-11S-JHP SL LV-2 SL PI-2 PIN SR 10400611 HW 2.0/5 S-CU-JHP-A SET PVACR/L 1212H-11S-JHP SL LV-2 SL PI-2 PIN SR 10400611 HW 2.0/5 SR 5/16UNF TL360 S-CU-JHP-A SET PVACR/L 1616K-11S-JHP SL LV-2 SL PI-2 PIN SR 10400611 HW 2.0/5 SR 5/16UNF TL360 S-CU-JHP-A SET PVACR 2020K-11S-JHP SL LV-2 SL PI-2 PIN SR 10400611 HW 2.5/5 SR 5/16UNF TL360 S-CU-JHP-A SET 89
