Токарные инструменты Iscar (часть 1) 2026 - страница 198

TURNING INSERTS 55° 60° 93º-95º MAX DNMG-F3P 62.5º 30º MAX Double-Sided 55° Rhombic 27° IC MAX Inserts for Semi-Finishing 93° and Finishing on Steel RE S L Dimensions Tough 1 Hard Recommended Machining Data IC8250 IC8150 ap f IC830 IC807 Designation L IC S RE (mm) (mm/rev) DNMG 110404-F3P 11.63 9.52 4.76 0.40 • • • • 0.80-3.00 0.07-0.25 DNMG 110408-F3P 11.63 9.52 4.76 0.80 • • • • 0.80-3.50 0.08-0.25 DNMG 110412-F3P 11.63 9.52 4.76 1.20 • • • • 1.40-4.00 0.10-0.25 DNMG 150404-F3P 15.50 12.70 4.76 0.40 • • • • 0.80-3.00 0.07-0.25 DNMG 150408-F3P 15.50 12.70 4.76 0.80 • • • • 0.80-3.50 0.08-0.25 DNMG 150412-F3P 15.50 12.70 4.76 1.20 • • • • 1.40-4.00 0.10-0.25 DNMG 150604-F3P 15.50 12.70 6.35 0.40 • • • • 0.80-3.00 0.07-0.25 DNMG 150608-F3P 15.50 12.70 6.35 0.80 • • • • 0.80-3.50 0.08-0.25 DNMG 150612-F3P 15.50 12.70 6.35 1.20 • • • • 1.40-4.00 0.10-0.25 • For user guide and cutting speed recommendations, see pages 160-170, 274-278 For tools, see pages: A/S-PDUNR/L (140) • AVC-DDUNR/L-VH (128) • C#-DDJNR/L (40) • C#-PDJNR/L-JHP (38) • DDJNR/L (39) • HSK A63WH-DDJNR/L (40) • HSK A63WH-DDNNN (41) • PDJNR/L (36) • PDJNR/L-JHP (37) • PDJNR/L-JHP-MC (37) • PDJNR/L-PAD-JHP (38) • S-DDUNR/L (139) • AVC-DDUNR/L (126) • DDJNR/L-JHP-MC (39) 55° 60° 93º-95º MAX DNMG-M3P 62.5º 30º MAX Double-Sided 55° Rhombic 27° IC MAX Inserts for Medium Machining 93° Conditions on Steel RE S L Dimensions Tough 1 Hard Recommended Machining Data ap f IC8250 IC8150 IC5010 IC5005 IC830 IC807 Designation L IC S RE (mm) (mm/rev) DNMG 110408-M3P 11.63 9.52 4.76 0.80 • • • • 0.50-5.00 0.15-0.50 DNMG 110412-M3P 11.63 9.52 4.76 1.20 • • • 0.80-5.00 0.18-0.60 DNMG 150408-M3P 15.50 12.70 4.76 0.80 • • • • • • 0.50-6.00 0.15-0.50 DNMG 150412-M3P 15.50 12.70 4.76 1.20 • • 0.80-6.00 0.18-0.60 DNMG 150608-M3P 15.50 12.70 6.35 0.80 • • • • 0.50-6.00 0.15-0.50 DNMG 150612-M3P 15.50 12.70 6.35 1.20 • • • • 0.80-6.00 0.18-0.60 • For user guide and cutting speed recommendations, see pages 160-170, 274-278 For tools, see pages: A/S-PDUNR/L (140) • AVC-DDUNR/L (126) • AVC-DDUNR/L-VH (128) • C#-DDJNR/L (40) • C#-PDJNR/L-JHP (38) • DDJNR/L (39) • HSK A63WH-DDJNR/L (40) • HSK A63WH-DDNNN (41) • PDJNR/L (36) • PDJNR/L-JHP (37) • PDJNR/L-JHP-MC (37) • PDJNR/L-PAD-JHP (38) • S-DDUNR/L (139) • DDJNR/L-JHP-MC (39) 196 ISCAR
