TURNING INSERTS RE XOMT-DT 88º Inserts for DR Drills and Boring Bars IC S Dimensions Tough 1 Hard IC520M IC328 IC250 IC350 IC908 IC28 Designation IC S RE XOMT 060204-DT 6.16 2.56 0.40 • • • • • • • Two cutting edges • For hard materials and interrupted cut For tools, see pages: A-SXFOR-DR (157) • A-SXFOR/L (157) 60° 91º 91º 95º TCMT-F3P 91º Triangular Inserts with a Positive Flank for Semi-Finishing and L Finish Turning on Steel D1 RE 7° IC S Dimensions Tough 1 Hard Recommended Machining Data ap f IC8250 IC8150 IC830 IC807 Designation L IC S RE D1 (mm) (mm/rev) TCMT 090202-F3P 9.60 5.56 2.38 0.20 2.50 • • • • 0.06-1.70 0.03-0.14 TCMT 090204-F3P 9.60 5.56 2.38 0.40 2.50 • • • • 0.10-1.70 0.05-0.20 TCMT 110202-F3P 11.00 6.35 2.38 0.20 2.80 • • • • 0.06-1.70 0.03-0.14 TCMT 110204-F3P 11.00 6.35 2.38 0.40 2.80 • • • • 0.10-1.70 0.05-0.20 TCMT 110208-F3P 11.00 6.35 2.38 0.80 2.80 • • • • 0.13-1.70 0.07-0.28 TCMT 16T304-F3P 16.50 9.52 3.97 0.40 4.40 • • • • 0.10-1.70 0.05-0.20 • For user guide and cutting speed recommendations, see pages 160-170, 274-278 For tools, see pages: E-STFCR-HEAD (151) • S-MTLCR/L-W (151) • S-STFCR/L (151) • S-STLCR/L (152) • STFCR/L (92) • STGCR/L (93) 60° 91º 91º 95º TCMT-M3P 91º Triangular Inserts with a 7° Positive Flank for Medium L Machining Turning on Steel D1 RE 7° IC S Dimensions Tough 1 Hard Recommended Machining Data ap f IC8250 IC8150 IC807 Designation L S RE D1 IC (mm) (mm/rev) TCMT 110204-M3P 11.00 2.38 0.40 2.80 6.35 • • • 0.40-2.50 0.08-0.25 TCMT 110208-M3P 11.00 2.38 0.80 2.80 6.35 • • • 0.80-3.00 0.10-0.30 TCMT 16T304-M3P 16.50 3.97 0.40 4.40 9.52 • • • 0.40-3.00 0.08-0.25 TCMT 16T308-M3P 16.50 3.97 0.80 4.40 9.52 • • • 0.80-3.50 0.10-0.30 TCMT 16T312-M3P 16.50 3.97 1.20 4.40 9.52 • • • 0.80-3.50 0.12-0.35 • For user guide and cutting speed recommendations, see pages 160-170, 274-278 For tools, see pages: E-STFCR-HEAD (151) • S-MTLCR/L-W (151) • S-STFCR/L (151) • S-STLCR/L (152) • STFCR/L (92) • STGCR/L (93) 255
