Токарные инструменты Iscar (часть 1) 2026 - страница 588

PARTING GFT-C Thin Parting, Grooving & Slitting Single-Ended Inserts for Soft Materials CW RE Dimensions Tough 1 Hard Recommended Machining Data f groove IC1028 IC1008 Designation CW RE (mm/rev) GFT 1.6C-0.16 1.60 0.16 • • 0.05-0.15 For tools, see pages: ADMP D22 (585) LF ASMBL CUTDIA CNT (typx3) THMPR/L D45-JHP H Bar Max Holders with High-Pressure HF HBH Coolant Channels for Pentagonal HBL TANG-GRIP Adapters OAL WF B Designation H HF HBH B WF CUTDIA LF ASMBL OAL HBL CNT THMPR/L 20-D45-JHP 20.0 20.1 18.0 20.0 17.35 45.0 107.60 112.00 42.0 G1/8 THMPR/L 25-D45-JHP 25.0 25.1 13.0 25.0 22.35 45.0 120.60 125.00 40.0 G1/8 For tools, see pages: ADMP D45 (586) Spare Parts Designation THMPR/L 20-D45-JHP SR M3X8 ISO 14580 BLACK T-10/5 PLG G1/8 TL360 HW 5.0 THMPR/L 25-D45-JHP SR M3X8 ISO 14580 BLACK T-10/5 PLG G1/8 TL360 HW 5.0 CUTDIA ADMP D45 D Parting and Grooving Adapters with 5 Pockets for TANG-GRIP Tangentially Clamped Inserts CW WB Designation CWN(1) CWX(2) WB D CUTDIA Insert ADMP D45-2.0 1.80 2.40 1.60 42 45.0 TAG 2 ADMP D45-3.0 2.80 3.50 2.50 42 45.0 TAG 3 • For user guide, see pages 606-615 (1) Minimum cutting width (2) Maximum cutting width For inserts, see pages: TAG N-A (573) • TAG N-C (full radius) (569) • TAG N-C/W/M (568) • TAG N-HF (568) • TAG N-J/JS/JT (570) • TAG N-LF (572) • TAG N-MF (570) • TAG N-UT (572) • TAG R/L-C (569) • TAG R/L-J/JS (571) For holders, see pages: THMPR/L D45-JHP (586) Tmax Dmax THMPR/L...-D45-JHP Tmax. to Dmax. Tmax T≤3.0 T≤4.0 T≤5.0 T≤6.0 T≤7.0 T≤8.0 T≤9.0 T≤10.0 T≤22.5 Dmax 85 80 75 70 65 60 55 50 45 Spare Parts Designation ADMP D45-2.0 ETG 2* ADMP D45-3.0 ETG 3-4-SH* * Optional, to be ordered separately 586 ISCAR
