ACCESSORIES & SPARE PARTS SRKIN PRESET SCREW Preset Screw for SRKIN Thermal TDZ CND Shrink Collets with Coolant Holes OAL Designation TDZ OAL CND(1) Key SS PRESET M5X18B M5X0.8 18.00 2.10 2.50 EM E/SRKIN PRESET M6X20B M6X1 20.00 2.50 3.00 EM E/SRKIN PRESET M8X20B M8X1.25 20.00 3.50 4.00 EM E/SRKIN PRESET M10X18B M10X1.5 18.00 4.50 5.00 EM E/SRKIN PRESET M12X18B M12X1.75 18.00 5.50 6.00 EM E/SRKIN PRESET M16X20B M16X2 20.00 7.50 6.00 EM E/SRKIN PRESET M16X25B M16X2 25.00 7.50 6.00 SRKIN (1) Coolant entry diameter 1 2 Key PRESET CX THOD BD Preset Screws for SRKIN Thermal Shrink Chucks LH LH OAL Designation THOD OAL BD LH Key Fig. PRESET CX M10X16 M10 18.20 11.20 2.2 5.00 1. PRESET CX M12X16 M12 18.20 15.00 2.2 6.00 1. PRESET CX M16X14 M16 17.00 18.80 3.0 8.00 1. PRESET CX M5X5 M5 7.00 6.50 2.5 2.50 2. PRESET CX M5X13 M5 15.00 5.80 2.2 2.50 2. PRESET CX M6X12 M6 14.00 8.00 2.0 3.00 1. PRESET CX M8X16 M8 18.20 9.30 2.2 4.00 1. New COOLING TUBE C# Cooling Tubes for CAMFIX CRKS (ISO 26623-1) Shanks LPR OAL Designation LPR CRKS OAL COOLING TUBE C4 12.00 M14x1.5 25.40 COOLING TUBE C5 14.00 M16x1.5 28.50 COOLING TUBE C6 15.00 M20x2 31.00 COOLING TUBE C8 15.00 M20x2 31.50 • Refer to machine manual before mounting CAMFIX Cooling Tube • Check that clamping drawbar has O-ring inside • Apply Loctite 542 (or equivalent) on coolant tube thread to secure/seal the thread • Mount cooling tube (ONLY) by using Cooling Tube C# wrench with “mount” side WRENCH COOL TUBE C# Remove Mount Clamping and Removing BD Wrenches for CAMFIX (ISO 26623-1) Cooling Tubes DRVS OAL Designation OAL BD DRVS(1) WRENCH COOL TUBE C4 45.00 17.80 15.0 WRENCH COOL TUBE C5 50.00 20.80 16.9 WRENCH COOL TUBE C6 60.00 27.80 19.0 WRENCH COOL TUBE C8 60.00 31.80 22.0 WRENCH COOL TUBE C10 75.00 42.80 25.9 (1) Torque key size 812 ISCAR
