CAMFIX DIN 26623-1 LSCWS √N5 ADJRGA A 0.003 A 50-52 HRc C#-SRKIN THID 4.5° Thermal Shrink Chucks with Integral CAMFIX (ISO 26623-1) DCONMS BTED BD Tapered Shanks for Solid Carbide, HSS and Steel Tools LB DCONWS G2.5 LBX 25,000 RPM or U<1.0 gmm LPR kg Designation DCONMS DCONWS BTED BD LPR LBX LB ADJRGA LSCWS THID Key(1) DCP(2) C4 SRKIN 6X75 40.00 6.00 21.00 27.00 75.00 55.0 38.10 11.00 36.0 M5 2.50 1 0.00 C4 SRKIN 8X75 40.00 8.00 21.00 27.00 75.00 55.0 38.10 11.00 36.0 M6 3.00 1 0.46 C4 SRKIN 10X75 40.00 10.00 24.00 32.00 75.00 55.0 50.80 11.00 42.0 M8 4.00 1 0.49 C4 SRKIN 12X75 40.00 12.00 24.00 32.00 75.00 55.0 50.80 11.00 47.0 M10 5.00 1 0.48 C4 SRKIN 14X80 40.00 14.00 27.00 34.00 80.00 60.0 44.50 11.00 47.0 M10 5.00 1 0.55 C4 SRKIN 16X80 40.00 16.00 27.00 34.00 80.00 60.0 44.50 11.00 50.0 M12 6.00 1 0.53 C4 SRKIN 18X80 40.00 18.00 33.00 42.00 80.00 60.0 57.20 11.00 50.0 M12 6.00 1 0.66 C4 SRKIN 20X85 40.00 20.00 33.00 42.00 85.00 65.0 57.20 11.00 52.0 M16 8.00 1 0.13 C5 SRKIN 6X75 50.00 6.00 21.00 27.00 75.00 55.0 38.10 11.00 36.0 M5 2.50 1 0.62 C5 SRKIN 8X75 50.00 8.00 21.00 27.00 75.00 55.0 38.10 11.00 36.0 M6 3.00 1 0.63 C5 SRKIN 10X75 50.00 10.00 24.00 32.00 75.00 55.0 51.30 11.00 42.0 M8 4.00 1 0.67 C5 SRKIN 12X75 50.00 12.00 24.00 32.00 75.00 55.0 51.30 11.00 47.0 M10 5.00 1 0.64 C5 SRKIN 14X80 50.00 14.00 27.00 34.00 80.00 60.0 44.50 11.00 47.0 M10 5.00 1 0.73 C5 SRKIN 16X80 50.00 16.00 27.00 34.00 80.00 60.0 44.50 11.00 50.0 M12 6.00 1 0.68 C5 SRKIN 18X80 50.00 18.00 33.00 42.00 80.00 60.0 57.20 11.00 50.0 M12 6.00 1 0.84 C5 SRKIN 20X85 50.00 20.00 33.00 42.00 85.00 65.0 57.20 11.00 52.0 M16 8.00 1 0.85 C5 SRKIN 25X90 50.00 25.00 44.00 53.00 90.00 70.0 57.20 11.00 58.0 M16 8.00 1 1.13 C6 SRKIN 6X80 63.00 6.00 21.00 27.00 80.00 58.0 38.10 11.00 36.0 M5 2.50 1 0.95 C6 SRKIN 8X80 63.00 8.00 21.00 27.00 80.00 58.0 38.10 11.00 36.0 M6 3.00 1 0.94 C6 SRKIN 10X80 63.00 10.00 24.00 32.00 80.00 58.0 50.80 11.00 42.0 M8 4.00 1 1.07 C6 SRKIN 12X80 63.00 12.00 24.00 32.00 80.00 58.0 50.80 11.00 47.0 M10 5.00 1 1.01 C6 SRKIN 14X85 63.00 14.00 27.00 34.00 85.00 63.0 44.50 11.00 47.0 M10 5.00 1 1.08 C6 SRKIN 16X85 63.00 16.00 27.00 34.00 85.00 63.0 44.50 11.00 50.0 M12 6.00 1 1.06 C6 SRKIN 18X85 63.00 18.00 33.00 42.00 85.00 63.0 57.20 11.00 50.0 M12 6.00 1 1.21 C6 SRKIN 20X85 63.00 20.00 33.00 42.00 85.00 63.0 57.20 11.00 52.0 M16 8.00 1 1.16 C6 SRKIN 25X90 63.00 25.00 44.00 53.00 90.00 68.0 57.20 11.00 58.0 M16 8.00 1 1.50 C6 SRKIN 32X95 63.00 32.00 44.00 53.00 95.00 73.0 57.20 11.00 58.0 M16 8.00 1 1.46 • The adjustment screw has an internal coolant hole • Use only inductive heating device for SRKIN holders (1) Hex key size for the rear stopper screw (2) 1 - Slot for data chip, 0 - Without slot for data chip 778-780 784-786 Spare Parts Designation C4 SRKIN 6X75 PRESET M5X18B COOLING TUBE C4* WRENCH COOL TUBE C4* C4 SRKIN 8X75 PRESET M6X20B COOLING TUBE C4* WRENCH COOL TUBE C4* C4 SRKIN 10X75 PRESET CX M8X16 COOLING TUBE C4* WRENCH COOL TUBE C4* C4 SRKIN 12X75 PRESET CX M10X16 COOLING TUBE C4* WRENCH COOL TUBE C4* C4 SRKIN 14X80 PRESET CX M10X16 COOLING TUBE C4* WRENCH COOL TUBE C4* C4 SRKIN 16X80 PRESET CX M12X16 COOLING TUBE C4* WRENCH COOL TUBE C4* C4 SRKIN 18X80 PRESET CX M12X16 COOLING TUBE C4* WRENCH COOL TUBE C4* C4 SRKIN 20X85 PRESET CX M16X14 COOLING TUBE C4* WRENCH COOL TUBE C4* C5 SRKIN 6X75 PRESET M5X18B COOLING TUBE C5* WRENCH COOL TUBE C5* C5 SRKIN 8X75 PRESET M6X20B COOLING TUBE C5* WRENCH COOL TUBE C5* C5 SRKIN 10X75 PRESET CX M8X16 COOLING TUBE C5* WRENCH COOL TUBE C5* C5 SRKIN 12X75 PRESET CX M10X16 COOLING TUBE C5* WRENCH COOL TUBE C5* C5 SRKIN 14X80 PRESET CX M10X16 COOLING TUBE C5* WRENCH COOL TUBE C5* C5 SRKIN 16X80 PRESET CX M12X16 COOLING TUBE C5* WRENCH COOL TUBE C5* C5 SRKIN 18X80 PRESET CX M12X16 COOLING TUBE C5* WRENCH COOL TUBE C5* C5 SRKIN 20X85 PRESET CX M16X14 COOLING TUBE C5* WRENCH COOL TUBE C5* C5 SRKIN 25X90 PRESET CX M16X14 COOLING TUBE C5* WRENCH COOL TUBE C5* C6 SRKIN 6X80 PRESET M5X18B COOLING TUBE C6* WRENCH COOL TUBE C6* C6 SRKIN 8X80 PRESET M6X20B COOLING TUBE C6* WRENCH COOL TUBE C6* C6 SRKIN 10X80 PRESET CX M8X16 COOLING TUBE C6* WRENCH COOL TUBE C6* C6 SRKIN 12X80 PRESET CX M10X16 COOLING TUBE C6* WRENCH COOL TUBE C6* C6 SRKIN 14X85 PRESET CX M10X16 COOLING TUBE C6* WRENCH COOL TUBE C6* C6 SRKIN 16X85 PRESET CX M12X16 COOLING TUBE C6* WRENCH COOL TUBE C6* C6 SRKIN 18X85 PRESET CX M12X16 COOLING TUBE C6* WRENCH COOL TUBE C6* C6 SRKIN 20X85 PRESET CX M16X14 COOLING TUBE C6* WRENCH COOL TUBE C6* C6 SRKIN 25X90 PRESET CX M16X14 COOLING TUBE C6* WRENCH COOL TUBE C6* C6 SRKIN 32X95 PRESET CX M16X14 COOLING TUBE C6* WRENCH COOL TUBE C6* * Optional, to be ordered separately 700 ISCAR
