CAMFIX DIN 26623-1

C#-EM

Державки для фрез DIN 1835 Form B Weldon с коническими хвостовиками CAMFIX (ISO 26623-1)

Обозначение	DCONMS	DCONWS	BD	LPR	LB	CRKS	DCP(1)	Масса, кг	Фреза	Ключ	Доп. принадлежности
C3 EM 6X45	32.00	6.00	25.00	45.00	30.0	M12	0	0.23	SR M6X10 DIN1835B	HW 3.0*
C3 EM 8X45	32.00	8.00	28.00	45.00	30.0	M12	0	0.25	SR M8X10 DIN1835-B	HW 4.0*
C3 EM10X50	32.00	10.00	35.00	50.00	35.0	M12	0	0.35	SR M10X12 DIN1835-B	HW 5.0*
C3 EM12X55	32.00	12.00	42.00	55.00	40.0	M12	0	0.40	SR M12X16 DIN1835-B	HW 6.0*
C4 EM10X50	40.00	10.00	35.00	50.00	30.0	M14	1	0.42	SR M10X12 DIN1835-B	HW 5.0*	COOLING TUBE C4* WRENCH COOL TUBE C4*
C4 EM12X55	40.00	12.00	42.00	55.00	35.0	M14	1	0.54	SR M12X16 DIN1835-B	HW 6.0*	COOLING TUBE C4* WRENCH COOL TUBE C4*
C4 EM14X55	40.00	14.00	44.00	55.00	35.0	M14	1	0.57	SR M12X16 DIN1835-B	HW 6.0*	COOLING TUBE C4* WRENCH COOL TUBE C4*
C4 EM16X60	40.00	16.00	48.00	60.00	40.0	M14	1	0.68	SR M14X16 DIN1835-B	HW 6.0*	COOLING TUBE C4* WRENCH COOL TUBE C4*
C4 EM6X50	40.00	6.00	25.00	50.00	30.0	M14	1	0.35	SR M6X10 DIN1835B	HW 3.0*	COOLING TUBE C4* WRENCH COOL TUBE C4*
C4 EM8X50	40.00	8.00	28.00	50.00	30.0	M14	1	0.37	SR M8X10 DIN1835-B	HW 4.0*	COOLING TUBE C4* WRENCH COOL TUBE C4*
C5 EM10X55	50.00	10.00	35.00	55.00	35.0	M16	1	0.69	SR M10X12 DIN1835-B	HW 5.0*	COOLING TUBE C5* WRENCH COOL TUBE C5*
C5 EM12X60	50.00	12.00	42.00	60.00	40.0	M16	1	0.83	SR M12X16 DIN1835-B	HW 6.0*	COOLING TUBE C5* WRENCH COOL TUBE C5*
C5 EM14X60	50.00	14.00	44.00	60.00	40.0	M16	1	0.87	SR M12X16 DIN1835-B	HW 6.0*	COOLING TUBE C5* WRENCH COOL TUBE C5*
C5 EM16X60	50.00	16.00	48.00	60.00	40.0	M16	1	0.85	SR M14X16 DIN1835-B	HW 6.0*	COOLING TUBE C5* WRENCH COOL TUBE C5*
C5 EM18X60	50.00	18.00	50.00	60.00	40.0	M16	1	0.46	SR M14X16 DIN1835-B	HW 6.0*	COOLING TUBE C5* WRENCH COOL TUBE C5*
C5 EM20X60	50.00	20.00	52.00	60.00	40.0	M16	1	0.90	SR M16X16 DIN1835-B	HW 8.0*	COOLING TUBE C5* WRENCH COOL TUBE C5*
C5 EM25X85	50.00	25.00	65.00	85.00	65.0	M16	1	1.66	SR M18X2X20 DIN1835-B	HW 10.0*	COOLING TUBE C5* WRENCH COOL TUBE C5*
C5 EM6X50	50.00	6.00	25.00	50.00	30.0	M16	1	0.52	SR M6X10 DIN1835B	HW 3.0*	COOLING TUBE C5* WRENCH COOL TUBE C5*
C5 EM8X50	50.00	8.00	28.00	50.00	30.0	M16	1	0.54	SR M8X10 DIN1835-B	HW 4.0*	COOLING TUBE C5* WRENCH COOL TUBE C5*
C6 EM10X60	63.00	10.00	35.00	60.00	38.0	M20	1	1.00	SR M10X12 DIN1835-B	HW 5.0*	COOLING TUBE C6* WRENCH COOL TUBE C6*
C6 EM12X60	63.00	12.00	42.00	60.00	38.0	M20	1	1.08	SR M12X16 DIN1835-B	HW 6.0*	COOLING TUBE C6* WRENCH COOL TUBE C6*
C6 EM14X60	63.00	14.00	44.00	60.00	38.0	M20	1	1.11	SR M12X16 DIN1835-B	HW 6.0*	COOLING TUBE C6* WRENCH COOL TUBE C6*
C6 EM16X65	63.00	16.00	48.00	65.00	43.0	M20	1	1.25	SR M14X16 DIN1835-B	HW 6.0*	COOLING TUBE C6* WRENCH COOL TUBE C6*
C6 EM18X65	63.00	18.00	50.00	65.00	43.0	M20	1	1.20	SR M14X16 DIN1835-B	HW 6.0*	COOLING TUBE C6* WRENCH COOL TUBE C6*
C6 EM20X65	63.00	20.00	52.00	65.00	43.0	M20	1	1.26	SR M16X16 DIN1835-B	HW 8.0*	COOLING TUBE C6* WRENCH COOL TUBE C6*
C6 EM25X80	63.00	25.00	65.00	80.00	58.0	M20	1	1.83	SR M18X2X20 DIN1835-B	HW 10.0*	COOLING TUBE C6* WRENCH COOL TUBE C6*
C6 EM32X90	63.00	32.00	72.00	90.00	68.0	M20	1	2.28	SR M20X2X20 DIN1835-B	HW 10.0*	COOLING TUBE C6* WRENCH COOL TUBE C6*
C6 EM40X100	63.00	40.00	90.00	100.00	78.0	M20	1	3.43	SR M20X2X20 DIN1835-B	HW 10.0*	COOLING TUBE C6* WRENCH COOL TUBE C6*
C6 EM6X55	63.00	6.00	25.00	55.00	33.0	M20	1	0.86	SR M6X10 DIN1835B	HW 3.0*	COOLING TUBE C6* WRENCH COOL TUBE C6*
C6 EM8X55	63.00	8.00	28.00	55.00	33.0	M20	1	0.89	SR M8X10 DIN1835-B	HW 4.0*	COOLING TUBE C6* WRENCH COOL TUBE C6*
C8 EM10X70	80.00	10.00	35.00	70.00	40.0	M20	1	2.00	SR M10X12 DIN1835-B	HW 5.0*	COOLING TUBE C8* WRENCH COOL TUBE C8*
C8 EM12X70	80.00	12.00	42.00	70.00	40.0	M20	1	2.20	SR M12X16 DIN1835-B	HW 6.0*	COOLING TUBE C8* WRENCH COOL TUBE C8*
C8 EM14X70	80.00	14.00	44.00	70.00	40.0	M20	1	2.10	SR M12X16 DIN1835-B	HW 6.0*	COOLING TUBE C8* WRENCH COOL TUBE C8*
C8 EM16X70	80.00	16.00	48.00	70.00	40.0	M20	1	2.16	SR M14X16 DIN1835-B	HW 6.0*	COOLING TUBE C8* WRENCH COOL TUBE C8*
C8 EM20X70	80.00	20.00	52.00	70.00	40.0	M20	1	2.18	SR M16X16 DIN1835-B	HW 8.0*	COOLING TUBE C8* WRENCH COOL TUBE C8*
C8 EM25X90	80.00	25.00	65.00	90.00	60.0	M20	1	2.89	SR M18X2X20 DIN1835-B	HW 10.0*	COOLING TUBE C8* WRENCH COOL TUBE C8*
C8 EM32X95	80.00	32.00	72.00	95.00	65.0	M20	1	3.20	SR M20X2X20 DIN1835-B	HW 10.0*	COOLING TUBE C8* WRENCH COOL TUBE C8*
C8 EM40X110	80.00	40.00	90.00	110.00	80.0	M20	1	4.73	SR M20X2X20 DIN1835-B	HW 10.0*	COOLING TUBE C8* WRENCH COOL TUBE C8*
C8 EM50X120	80.00	50.00	98.00	120.00	90.0	M20	1	5.30	SR M24X2X25 DIN1835-B	HW 12.0*	COOLING TUBE C8* WRENCH COOL TUBE C8*
C8 EM6X70	80.00	6.00	25.00	70.00	40.0	M20	1	1.86	SR M6X10 DIN1835B	HW 3.0*	COOLING TUBE C8* WRENCH COOL TUBE C8*
C8 EM8X70	80.00	8.00	28.00	70.00	40.0	M20	1	1.90	SR M8X10 DIN1835-B	HW 4.0*	COOLING TUBE C8* WRENCH COOL TUBE C8*

(1) 1 — слот для чипа данных, 0 — без слота для чипа данных
* По желанию, заказывать отдельно

Фрезерные инструменты Iscar 2026 - страница 699
