CENTER ALIGNMENT DEVICES 1 58-60 HRc √N5 DCONNWS 4x90º D4 ADJ ER NOSE DCONXWS Radial and Angular Adjustable DBC DCONMS BD DF Collet Chuck Flanges 45º 2 4x90º THID LSCMS LB (1)Adjustment screw (2)Clamping screw LPR Designation DCONNWS(1) DCONXWS(2) LPR LB LSCMS BD DF DBC DCONMS D4 THID ADJ ER32 NOSE 2.0 20.0 75.00 53.0 10.00 50.00 70.00 53.00 35.00 6.60 M8x1 (1) Minimum diameter (2) Maximum diameter Spare Parts Designation 1 - Adjustment screw ADJ ST1 D2.756 2 - Clamping screw ADJ ST25 D70 ADJ ST32 D70 ADJ HSK A 63 D70 ADJ HSK A 100 D70 ADJ CAT40 D2.756 ADJ CAT50 D2.756 ADJ BT40 D70 ADJ BT50 D70 766-773 633, 755 Spare Parts Designation ADJ ER NOSE NUT ER32 TOP ADJUST SPACER 9.5X5 PRESET ER-JET 22X1.5 SR M8X1X16 DIN916 58-60 HRc ADJ ST FINE-FIT Center Alignment √N5 DCONMS DCONWS BD Shank and Base with Cylindrical Shanks with a Clamping Flat LS LF Designation DCONMS LF LS BD DCONWS ADJ ST25 D70 25.00 20.00 80.00 70.00 35.00 SR M8X1X16 DIN916 SR M6X30 DIN912 OR 21X4N HW 4.0* ADJUST SPACER 9.5X5* HW 5.0* ADJ ST32 D70 32.00 20.00 80.00 70.00 35.00 SR M8X1X16 DIN916 SR M6X30 DIN912 OR 21X4N HW 4.0* ADJUST SPACER 9.5X5* HW 5.0* * Optional, to be ordered separately LPR 58-60 HRc LBX ADJ HSK A LB (1) FINE-FIT Center Alignment Shank √N5 and Base with a DIN69893 DCONMS HSK Tapered Shank for DCONWS BD Specially Tailored Toolholders BD_2 kg Designation DCONMS LPR LBX LB DCONWS BD BD_2 DCP(1) ADJ HSK A63 D70 63.00 60.00 34.0 18.00 35.00 70.00 46.00 1 1.24 ADJ HSK A100 D70 100.00 55.00 26.0 - 35.00 70.00 - 1 2.63 • (1) Use 4 mm hex key for screw adjustment. • A cooling tube must be used with all coolant through HSK spindles (to be ordered separately) (1) 1 - Slot for data chip, 0 - Without slot for data chip Spare Parts Designation ADJ HSK A63 D70 SR M8X1X16 DIN916 SR M6X30 DIN912 OR 21X4N ADJUST SPACER 9.5X5* HW 4.0* COOLING TUBE HSK A63* WRENCH COOL TUBE HSK63* HW 5.0* ADJ HSK A100 D70 SR M8X1X16 DIN916 SR M6X30 DIN912 OR 21X4N ADJUST SPACER 9.5X5* HW 4.0* COOLING TUBE HSK A100* WRENCH COOL TUBE HSK100* HW 5.0* * Optional, to be ordered separately 752 ISCAR
