Фрезерные инструменты Iscar 2026 - страница 727

BT MAS-403 BD LSCWS A 0.003 A AT3 Taper 50-52 HRc SS ADJRGA BT-FC-SRK 4˚ Thermal Shrink Chucks with √N5 BT MAS-403 Face Contact BTED CRKS DCONWS AD Tapered Shanks THID LB G2.5 LBX 25,000 RPM LPR or U<1.0 gmm kg Designation SS DCONWS BTED BD LPR LBX LB ADJRGA LSCWS THID CRKS DCP(1) BT30 FC SRK 3X50 30 3.00 9.93 15.00 72.00 50.0 36.30 0.00 10.0 M6 M12 0 0.32 BT30 FC SRK 4X50 30 4.00 9.93 15.00 72.00 50.0 36.30 0.00 12.0 M6 M12 0 0.46 BT30 FC SRK 6X50 30 6.00 10.88 16.00 72.00 50.0 36.60 0.00 18.0 M8 M12 0 0.52 BT30 FC SRK 8X50 30 8.00 13.95 20.00 72.00 50.0 43.30 0.00 25.0 M10 M12 0 0.48 BT30 FC SRK12X50 30 12.00 20.03 26.00 72.00 50.0 42.70 10.00 42.0 M10 M12 0 0.53 • Use only inductive heating device for SRKIN holders • For through tool coolant, preset screw must be removed (1) 1 - Slot for data chip, 0 - Without slot for data chip Spare Parts Designation BT30 FC SRK 3X50 SR M6X10 DIN916 BT30 FC SRK 4X50 SR M6X10 DIN916 BT30 FC SRK 6X50 SR M8X12 DIN916 BT30 FC SRK 8X50 SR M10X10 DIN913 BT30 FC SRK12X50 PRESET M10X18B LSCWS √N5 DCONNWS 4.5˚ DCONXWS A 0.003 A 50-52 HRc BT-MS BD BD_2 QUICK-CLAMP System for CRKS Small Cutting Tools with BT LB BTED SS LBX MAS-403 Form AD Shank LPR OAL Designation DCONNWS(1) DCONXWS(2) SS BTED BD BD_2 LPR LB LBX OAL LSCWS CRKS DCP(3) BT40 MS6X60 3.00 6.00 BT40 15.00 17.80 26.20 87.00 36.00 60.00 152.40 33.00 M16 0 New (1) Minimum diameter (2) Maximum diameter (3) 1 - Slot for data chip, 0 - Without slot for data chip 725
