EXTENDED FLUTE CUTTERS T490 LNK-13-CF Extended Flute Endmills with DC Shank DCONMS CLICK-FIT Shanks Carrying T490 LNMT/HT 1306... APMX LH Tangentially Clamped Inserts LF OAL kg Designation DC APMX NOF(1) CICT(2) LH LF OAL DCONMS Shank T490 LNK-D50-59-4-CF4-13 50.00 59.00 4 20 - 73.00 115.00 44.00 CF4 0.82 SR 34-535-SN BLD T15/S7 SW6-T-SH (1) Number of flutes (2) Number of inserts (or edges for solid tool) For inserts, see pages: T490 LNAR-P (548) • T490 LNMT 1306PNTR-FW (547) • T490 LNMT/LNHT/LNAR 1306 (546) Shank T490 LNK-13-BT Extended Flute Endmills with DC DF BT-MAS-403 Tapered Shanks Carrying T490 LNMT/HT 13... Tangentially Clamped Inserts APMX LH LF kg Designation DC APMX NOF(1) CICT(2) LH LF Shank DF CSP(3) T490LNK-D50-059-4-BT50-13 50.00 59.00 4 20 80.5 120.00 BT-MAS-403 100.00 1 4.34 SR 34-535-SN BLD T15/S7 SW6-T-SH T490LNK-D50-105-3-BT50-13 50.00 105.00 3 27 130.0 168.00 BT-MAS-403 100.00 0 4.99 SR 34-535-SN BLD T15/S7 SW6-T-SH T490LNK-D63-117-4-BT50-13 63.00 117.00 4 40 150.0 188.00 BT-MAS-403 100.00 1 6.07 SR 34-535-SN BLD T15/S7 SW6-T-SH T490LNK-D80-082-4-BT50-13 80.00 82.00 4 28 135.0 173.00 BT-MAS-403 100.00 1 7.65 SR 34-535-SN BLD T15/S7 SW6-T-SH T490LNK-D80-128-4-BT50-13 80.00 128.00 4 44 162.0 200.00 BT-MAS-403 100.00 1 8.25 SR 34-535-SN BLD T15/S7 SW6-T-SH (1) Number of flutes (2) Number of inserts (or edges for solid tool) (3) 0 - Without coolant supply, 1 - With coolant supply For inserts, see pages: T490 LNAR-P (548) • T490 LNMT 1306PNTR-FW (547) • T490 LNMT/LNHT/LNAR 1306 (546) Shank T490 LNK-13-INT Extended Flute Endmills with DC DF DIN69871 Tapered Shanks Carrying T490 LNMT/HT 13... Tangentially Clamped Inserts APMX LH LF kg Designation DC APMX NOF(1) CICT(2) LH LF Shank DF T490LNKD50-082-3-INT50-13 50.00 82.00 3 21 126.0 145.00 DIN 69871 97.50 3.85 SR 34-535-SN BLD T15/S7 SW6-T-SH T490LNKD63-117-4-INT50-13 63.00 117.00 4 40 169.0 188.00 DIN 69871 97.50 5.46 SR 34-535-SN BLD T15/S7 SW6-T-SH T490LNKD80-082-4-INT50-13 80.00 82.00 4 28 154.0 173.00 DIN 69871 97.50 7.61 SR 34-535-SN BLD T15/S7 SW6-T-SH T490LNKD80-128-4-INT50-13 80.00 128.00 4 44 180.9 200.00 DIN 69871 97.50 7.92 SR 34-535-SN BLD T15/S7 SW6-T-SH (1) Number of flutes (2) Number of inserts (or edges for solid tool) For inserts, see pages: T490 LNAR-P (548) • T490 LNMT 1306PNTR-FW (547) • T490 LNMT/LNHT/LNAR 1306 (546) 278 ISCAR
