MILLING INSERTS RE W1 RE W1 HM90 APKT 1003 Inserts for General Use with Rd° 2 Helical Cutting Edges for APMX INSL APMX INSL High 90° Shoulder Accuracy BS BS S Recommended Dimensions Tough 1 Hard Machining Data ap fz IC5400 IC5600 IC882 IC330 IC328 IC716 IC830 IC928 IC950 IC380 IC808 IC908 IC810 IC910 IC28 Designation W1 INSL APMX S RE BS Fig. (mm) (mm/t) HM90 APKT 1003PDR 6.76 11.45 9.80 3.53 0.80 1.40 1 • • • • • • • • • • • • • • 1.20-8.00 0.08-0.15 HM90 APKT 100304PDR-SC 6.80 11.60 9.80 4.00 0.40 1.80 2 • 0.80-8.00 0.08-0.15 HM90 APKT 1003PDR-MM 6.70 11.50 9.80 3.50 0.80 1.60 3 • 1.20-8.00 0.08-0.15 HM90 APKT 1003PDTR-8M 6.76 11.45 9.80 3.53 0.80 1.40 4 • • 1.20-8.00 0.08-0.20 HM90 APKT 100304PDR 6.76 11.45 9.80 3.53 0.40 1.78 1 • • • • • • 0.80-8.00 0.08-0.15 HM90 APKT 100308R 6.76 11.45 9.80 3.53 0.80 1.00 5 • 1.20-8.00 0.08-0.15 HM90 APKT 100310PDR 6.76 11.45 9.80 3.53 1.00 1.00 1 • 1.40-8.00 0.08-0.15 HM90 APKT 100312PDR 6.76 11.45 9.20 3.53 1.20 1.00 1 • • • • 1.60-8.00 0.08-0.15 HM90 APKT 100316PDR 6.76 11.45 9.20 3.53 1.60 0.58 1 • • • • 2.00-8.00 0.08-0.15 HM90 APKT 100325PDR 6.76 10.40 9.20 3.53 2.50 - 1 • • • • 2.90-8.00 0.08-0.15 HM90 APKT 100330PDR 6.76 10.40 9.20 3.53 3.00 - 1 • • • • 3.40-8.00 0.08-0.15 • For inserts with corner radii larger than 1.5 mm, the cutter body should be modified • For cutting speed recommendations, see pages 616-620 For tools, see pages: APK-FE (279) • HM90 E90A-10 (32) • HM90 E90A-M-10 (39) • HM90 E90A-MM-10 (37) • HM90 E90A-MM-10-JHP (38) • HM90 F90AP-10 (236) • HM90 F90AP-10-JHP (237) • HM90 F90AP-AMT (237) 1 2 3 4 5 HM90 APKT 1003PDR-MM HM90 APKT 1003PDR-SC • Cutting edge geometry • Larger axial effective angle up to with low axial angle the middle of the insert length • Reinforced cutting edge • Reduced cutting forces, effective geometry, which provides up to 5 mm – the middle of better chipping resistance insert’s cutting edge length • Wide frontal wiper that leaves • Used for machining ductile high excellent surface finish with low strength materials. Parts such mismatch on the workpiece as shafts, gears, crankshafts, • Used for unfavorable connection rods, camshafts, etc. conditions and high feeds W1 HM90 APCR 100304PDFR-P/ DP Inserts with Positive Helical APMX lNSL Cutting Edges and Polished Rake for Machining Aluminum Rd° RE and High Temperature Alloys BS S Recommended Dimensions Tough 1 Hard Machining Data ap fz IC928 IC908 IC28 IC08 Designation W1 INSL APMX S RE BS Fig. (mm) (mm/t) HM90 APCR 100304PDFR-P 6.52 11.25 9.80 3.85 0.40 1.52 1 • • • • 0.80-8.00 0.07-0.25 HM90 APCR 100304PDFRDP 6.52 11.25 9.80 3.85 0.40 1.52 2 • 0.80-8.00 0.07-0.25 • Super positive peripherally ground chipformer • P - Polished rake DP- Polished rake and flank • Used for machining aluminum (fz 0.07-0.25), titanium (fz 0.05-0.08) and magnesium (fz 0.05-0.10) • Recommended for coarse pitch cutters • For cutting speed recommendations, see pages For tools, see pages: APK-FE (279) • HM90 E90A-10 (32) • HM90 E90A-M-10 (39) • HM90 E90A-MM-10 (37) • HM90 E90A-MM-10-JHP (38) • HM90 F90AP-10 (236) • HM90 F90AP-10-JHP (237) • HM90 F90AP-AMT (237) 1 2 515
