PROFILING TOOLS 1 TR6 TNCU TR6 ER-M THSZMS DCONMS Multifunction Endmills 2 DCX DC TRFF TXMT with FLEX-FIT Threaded APMX Adaptation That Carry Four 3 TR90 TXMT BHTA APMXU Different Insert Geometries LF 4 TR45 TXMT OAL Tool shown with TR6 TNCU inserts Designation DCX(1) DCX_2 DCX_3 DCX_4 DC DC_2DC_4 APMX APMX_2APMX_3APMX_4 APMXU(2) BHTA(3) CICT(4) LF LF_2 LF_3 LF_4 RMPX°_2 TR6 ER D16/0.63-2-M08-07 16.00 16.00 16.00 - 14.00 12.10 - 1.00 0.60 2.50 - 2.00 18.0 2 24.64 24.90 25.00 - 1.3 TR6 ER D20/0.79-4-M10-07 20.00 20.00 20.00 - 18.00 16.10 - 1.00 0.60 2.50 - 2.00 18.0 4 24.64 24.90 25.00 - 1.0 TR6 ER D25/0.98-5-M12-07 25.00 25.00 25.00 - 23.00 21.10 - 1.00 0.60 2.50 - 2.00 18.0 5 29.64 29.90 30.00 - 0.7 TR6 ER D32/1.26-6-M16-07 32.00 32.00 32.00 - 30.00 28.10 - 1.00 0.60 2.50 - 2.00 18.0 6 34.64 34.90 35.00 - 0.5 TR6 ER D35/1.38-6-M16-07 35.00 35.00 35.00 - 33.00 31.10 - 1.00 0.60 2.50 - 2.00 18.0 6 34.64 34.90 35.00 - 0.5 TR6 ER D25/0.98-3-M12-10 25.00 24.60 25.00 26.80 20.00 20.60 20.60 2.50 0.80 4.00 3.00 4.20 17.0 3 24.97 25.15 25.12 25.12 1.7 TR6 ER D32/1.26-4-M16-10 32.00 31.60 32.00 33.80 27.00 27.60 27.60 2.50 0.80 4.00 3.00 4.20 17.0 4 34.97 35.15 35.12 35.12 1.2 TR6 ER D35/1.38-5-M16-10 35.00 34.60 35.00 36.80 30.00 30.60 30.60 2.50 0.80 4.00 3.00 4.20 17.0 5 34.97 35.15 35.12 35.12 1.1 Designation OAL OAL_2 OAL_3 OAL_4 DCONMS THSZMS MIID(5) MIID_2(6) MIID_3(7) MIID_4(8) DRVS(9) TQ_3(10) kg TR6 ER D16/0.63-2-M08-07 42.20 42.40 42.50 - 13.00 M08 TR6 TNCU 070210 TRFF TXMT 0702 TR90 TXMT 070204 - 11.0 20 0.03 TR6 ER D20/0.79-4-M10-07 44.70 44.90 45.00 - 18.00 M10 TR6 TNCU 070210 TRFF TXMT 0702 TR90 TXMT 070204 - 15.0 29 0.05 TR6 ER D25/0.98-5-M12-07 51.70 51.90 52.00 - 21.00 M12 TR6 TNCU 070210 TRFF TXMT 0702 TR90 TXMT 070204 - 17.0 33 0.08 TR6 ER D32/1.26-6-M16-07 59.70 59.90 60.00 - 29.00 M16 TR6 TNCU 070210 TRFF TXMT 0702 TR90 TXMT 070204 - 25.0 40 0.18 TR6 ER D35/1.38-6-M16-07 59.70 59.90 60.00 - 29.00 M16 TR6 TNCU 070210 TRFF TXMT 0702 TR90 TXMT 070204 - 25.0 40 0.19 TR6 ER D25/0.98-3-M12-10 47.00 47.15 46.91 47.12 21.00 M12 TR6 TNCU 100425 TRFF TXMT 1004 TR90 TXMT 100408 TR45 TXMT 1004 19.0 33 0.06 TR6 ER D32/1.26-4-M16-10 60.00 60.15 59.91 60.12 29.00 M16 TR6 TNCU 100425 TRFF TXMT 1004 TR90 TXMT 100408 TR45 TXMT 1004 25.0 40 0.17 TR6 ER D35/1.38-5-M16-10 60.00 60.15 59.91 60.12 29.00 M16 TR6 TNCU 100425 TRFF TXMT 1004 TR90 TXMT 100408 TR45 TXMT 1004 25.0 40 0.18 • Note: The data refers to master inserts, for other insert radii and geometries refer to the table below • When mounting items with FLEX-FIT threaded adaptation to their holders, the mating surfaces and threaded areas must be thoroughly cleaned. Apply appropriate tightening torque to eliminate a gap between the mating faces. Estimated torque values are specified in the TQ_3 parameter (1) Cutting diameter maximum (2) For undercutting with TR6 TNCU/TNMU inserts only (3) For undercutting with TR6 TNCU/TNMU inserts only (4) Number of inserts (or edges for solid tool) (5) Master insert identification (6) Master insert identification 2 (7) Master insert identification 3 (8) Master insert identification 4 (9) Torque key size (10) Tool tightening torque Nxm For inserts, see pages: TR45 TXMT (613) • TR6 TNCU/MU (612) • TR90 TXMT (613) • TRFF TXMT (613) For holders, see pages: BT-ODP (FLEX-FIT) (359) • C#-ODP (FLEX-FIT) (359) • CAB M-M (FLEX-FIT) (358) • DIN69871-ODP (360) • ER-ODP (360) • HSK A-ODP (FLEX-FIT) (361) • S M (357) • S M-C-H (357) 314 ISCAR
