MILLING INSERTS RNGN (CER) Negative Round Double-Sided Rd° IC Ceramic Inserts for Machining Cast Iron, Hardened Steel, and Heat-Resistant Alloys S Dimensions Tough 1 Hard Recommended Machining Data ap fz IN16C IS45C IW10 IN20 IN16 IN10 IS55 IS45 IS26 IS15 IS14 Designation IC S (mm) (mm/t) RNGN 120700 E004 12.70 7.94 • • • • • 0.05-3.00 0.05-0.50 RNGN 120700 T01020 12.70 7.94 • • • • • 0.10-4.50 0.05-0.50 RNGN 120700 T00520 12.70 7.94 • • 0.05-3.00 0.05-0.50 RNGN 120700 P20015 12.70 7.94 • • • 0.05-3.00 0.05-0.50 • For user guide and cutting speed recommendations, see pages 616-620 For tools, see pages: FRN (320) H400 RNHU L Double-Sided Inserts with Four Rd° 5, 6 and 8 mm Radii Cutting APMX Edges for Profile Milling RE W1 S Dimensions Tough 1 Hard Recommended Machining Data ap fz IC330 IC830 IC808 Designation RE L W1 APMX S (mm) (mm/t) H400 RNHU 1004-AX (1) 5.00 9.20 9.30 7.50 4.70 • • 1.00-5.00 0.10-0.30 H400 RNHU 1004-HP (2) 5.00 9.20 9.30 7.50 4.05 • 1.00-5.00 0.10-0.30 H400 RNHU 1004-ML (3) 5.00 9.20 9.30 7.50 4.05 • • 1.00-5.00 0.10-0.30 H400 RNHU 1205-AX (1) 6.00 11.00 11.20 8.70 5.20 • • 2.00-6.00 0.15-0.30 H400 RNHU 1205-HP (2) 6.00 11.00 11.20 8.70 4.75 • • 2.00-6.00 0.15-0.30 H400 RNHU 1205-ML (3) 6.00 11.00 11.20 8.70 4.75 • • 2.00-6.00 0.15-0.30 H400 RNHU 1606-AX (1) 8.00 14.70 13.90 12.00 7.80 • • • 3.00-8.00 0.15-0.40 H400 RNHU 1606-HP (2) 8.00 14.70 13.90 12.00 7.80 • 3.00-8.00 0.15-0.40 H400 RNHU 1606-ML (3) 8.00 14.70 13.90 12.00 7.80 • • 3.00-8.00 0.15-0.40 • For cutting speed recommendations, see pages 616-620 (1) First priority for austenitic stainless steel, second priority for steel, ferritic and martensitic stainless (2) First priority for titanium and high temperature alloys, second priority for austenitic stainless steel (3) First priority for steel, ferritic and martensitic stainless steel, second priority for austenitic stainless steel For tools, see pages: H400 ER-10 (324) • H400 ER-12 (324) • H400 ER-M (325) • H400 FR-10 (325) • H400 FR-12 (326) • H400 FR-16 (327) ML HP AX IC H606 RXCU 1206 Double-Sided Round Rd° Inserts with Six Cutting Edges for Profile Milling RE S Dimensions Tough 1 Hard Recommended Machining Data ap fz IC330 IC830 IC808 Designation INSD RE S (mm) (mm/t) H606 RXCU 1206-AXMP (1) 12.20 6.00 5.90 • • • 2.00-6.00 0.10-0.40 H606 RXCU 1206-AXT (2) 12.20 6.00 5.90 • • 2.00-6.00 0.10-0.40 • For cutting speed recommendations, see pages 616-620 (1) For stainless steel and high temperature alloys (2) For steel and cast iron applications For tools, see pages: H606 ER-M (328) • H606 FR-12 (328) AXMP AXT 606 ISCAR
