Фрезерные инструменты Iscar 2026 - страница 654

DIN69871-A/B A 0.005 A AT3 Taper 2 1 LF LSCWS DIN69871-FM DBC DBC DIN 6357 Face Mill Holders with SS √N5 58-60 HRc THID THID DIN 69871 Form A/AD Taper Shanks THSZWS DCONWS BD CRKS kg Designation SS DCONWS BD DBC LF LSCWS THID THSZWS CRKS Fig. DCP(3) DIN69871 40 FM 40 (1) 40 40.00 88.00 66.70 60.00 27.00 M12 M20 M16 1. 0 2.25 DIN69871 50 FM 40X70 (1) 50 40.00 88.00 66.70 70.00 27.00 M12 M20 M24 1. 0 4.87 DIN69871 50 FM 60 (2) 50 60.00 128.00 101.60 70.00 40.00 M16 - M24 2. 0 7.32 • Peripheral clamping screws are not supplied. (1) Form AD (2) Form A (3) 1 - Slot for data chip, 0 - Without slot for data chip 802-805 Spare Parts Designation DIN69871 40 FM 40 M20 CLAMP SCREW SEM40 WRENCH M20 SEMC 40* DR. DOG 16 E DIN69871 50 FM 40X70 M20 CLAMP SCREW SEM40 WRENCH M20 SEMC 40* DR. DOG 16 E DIN69871 50 FM 60 DR. DOG 1E * Optional, to be ordered separately 652 ISCAR
