MILLING INSERTS OXMT 0507R08-FF OXMT 050705-R-HP OXMT 0507 IC L Octagonal High Feed 45° Inserts IC 45° 15° APMX S BS L APMX BS Dimensions Tough 1 Hard Recommended Machining Data ap fz IC830 IC808 Designation APMX IC BS S L (mm) (mm/t) OXMT 0507R08-FF (1) 1.20 14.50 0.80 7.00 5.00 • 0.50-1.20 0.50-1.80 OXMT 050705-R-HP (2) 2.70 15.10 1.24 7.00 4.30 • 0.50-2.50 0.12-0.30 • To be used without a seat • For cutting speed recommendations, see pages 616-620 (1) For high feed milling (2) 45° edge for austenitic stainless steel and high temperature alloys For tools, see pages: FF SOF (355) • SOE45 8/16 (52) • SOF45 (260) -FF -HP OECR Octagonal Milling Inserts IC with Positive Rake and Sharp Cutting Edges 45° APMX BS RE S Recommended Dimensions Tough 1 Hard Machining Data ap fz IC830 IC928 IC808 IC28 Designation IC APMX BS RE S (mm) (mm/t) OECR 060405AER 14.45 3.70 1.60 0.50 4.90 • 1.00-3.70 0.12-0.20 OECR 060405AER-P (1) 14.45 3.70 1.60 0.50 4.90 • • • 1.00-3.70 0.08-0.20 • For cutting speed recommendations, see pages 616-620 (1) Polished rake used for aluminum and titanium For tools, see pages: HOE-R06 (256) • HOF-R06 (256) OEMT/OEKT 060405 Octagonal Milling Inserts IC for General Use 45° APMX BS S RE Recommended Dimensions Tough 1 Hard Machining Data ap fz IC5400 IC5100 IC330 IC830 IC808 IC810 IC28 Designation IC APMX BS RE S (mm) (mm/t) OEMT 060405AER-76 14.27 2.50 1.60 0.50 4.74 • • • • • • • 1.00-2.45 0.15-0.25 • For cutting speed recommendations, see pages 616-620 For tools, see pages: HOE-R06 (256) • HOF-R06 (256) 575
