MILLING INSERTS W1 Rd° APCR 1003PDFR-P Super Positive Insert with a Polished Rake for LE/APMX INSL Machining Aluminum BS RE S Recommended Dimensions Tough 1 Hard Machining Data ap fz IC928 IC28 Designation W1 INSL S RE BS APMX (mm) (mm/t) APCR 1003PDFR-P 6.70 11.20 3.76 0.50 1.20 9.80 • • 0.90-8.00 0.07-0.25 • Super positive rake sharp ground helical cutting edge, for finishing on aluminum, stainless steel and high temperature alloys • For cutting speed recommendations, see pages 616-620 For tools, see pages: APK-FE (279) • HM90 E90A-10 (32) • HM90 E90A-M-10 (39) • HM90 E90A-MM-10 (37) • HM90 E90A-MM-10-JHP (38) • HM90 F90AP-10 (236) • HM90 F90AP-10-JHP (237) • HM90 F90AP-AMT (237) W1 Rd° APKR 1003PDR High Positive Inserts for Machining Stainless Steel and APMX INSL High Temperature Alloys BS RE S Recommended Dimensions Tough 1 Hard Machining Data ap fz IC330 IC328 IC716 IC840 IC928 IC28 Designation W1 INSL APMX S RE BS (mm) (mm/t) APKR 1003PDR-HM 6.70 11.20 9.80 3.76 0.50 1.20 • • • • 0.90-8.00 0.07-0.15 APKR 1003PDR-HP 6.70 11.50 9.80 3.80 0.80 1.90 • • 0.90-8.00 0.07-0.15 • For cutting speed recommendations, see pages 616-620 For tools, see pages: APK-FE (279) • HM90 E90A-10 (32) • HM90 E90A-M-10 (39) • HM90 E90A-MM-10 (37) • HM90 E90A-MM-10-JHP (38) • HM90 F90AP-10 (236) • HM90 F90AP-10-JHP (237) • HM90 F90AP-AMT (237) HM HP W1 Rd° APKT 1003PDR-HM Inserts with 2 Helical Cutting Edges for General Use APMX INSL BS RE S Recommended Dimensions Tough 1 Hard Machining Data IC520M IC50M IC30N ap fz IC330 IC328 IC830 IC928 IC635 IC250 IC950 IC910 IC28 IC20 Designation W1 INSL S APMX RE BS (mm) (mm/t) APKT 1003PDR-HM 6.70 10.95 3.55 9.80 0.50 1.20 • • • • • • • • • • • • • 0.90-8.00 0.08-0.15 • For cutting speed recommendations, see pages 616-620 For tools, see pages: APK-FE (279) • E90AC (50) • HM90 E90A-10 (32) • HM90 E90A-M-10 (39) • HM90 E90A-MM-10 (37) • HM90 E90A-MM-10-JHP (38) • HM90 F90AP-10 (236) • HM90 F90AP-10-JHP (237) • HM90 F90AP-AMT (237) 517
