EB-A2 (обработка рёбер)

2-зубая, спираль 30°, фреза концевая сферическая из твердого сплава для обработки рёбер для материалов с твёрдостью до 55 HRC

Размеры

Артикул	DC	DCONMS	APMX	OAL	LU	DN	RE	Зубья	FHA	Хвостовик	RETOL	fz (мм/зуб)	IC903
EB-A2 004-006/01C4M45	0.40	4.00	0.60	45.00	1.0	0.36	0.20	2	30.0	C	0.010	0.0030-0.0060	•
EB-A2 004-006/02C4M45	0.40	4.00	0.60	45.00	2.0	0.36	0.20	2	30.0	C	0.010	0.0030-0.0060	•
EB-A2 004-006/03C4M45	0.40	4.00	0.60	45.00	3.0	0.36	0.20	2	30.0	C	0.010	0.0030-0.0060	•
EB-A2 005-007/02C4M45	0.50	4.00	0.70	45.00	2.0	0.45	0.25	2	30.0	C	0.010	0.0030-0.0060	•
EB-A2 005-007/04C4M45	0.50	4.00	0.70	45.00	4.0	0.45	0.25	2	30.0	C	0.010	0.0030-0.0060	•
EB-A2 005-007/06C4M45	0.50	4.00	0.70	45.00	6.0	0.45	0.25	2	30.0	C	0.010	0.0030-0.0060	•
EB-A2 005-007/08C4M45	0.50	4.00	0.70	45.00	8.0	0.45	0.25	2	30.0	C	0.010	0.0030-0.0060	•
EB-A2 006-009/02C4M45	0.60	4.00	0.90	45.00	2.0	0.55	0.30	2	30.0	C	0.010	0.0040-0.0080	•
EB-A2 006-009/04C4M45	0.60	4.00	0.90	45.00	4.0	0.55	0.30	2	30.0	C	0.010	0.0040-0.0080	•
EB-A2 008-012/02C4M45	0.80	4.00	1.20	45.00	2.0	0.75	0.40	2	30.0	C	0.010	0.0040-0.0080	•
EB-A2 008-012/04C4M45	0.80	4.00	1.20	45.00	4.0	0.75	0.40	2	30.0	C	0.010	0.0040-0.0080	•
EB-A2 008-012/06C4M45	0.80	4.00	1.20	45.00	6.0	0.75	0.40	2	30.0	C	0.010	0.0040-0.0080	•
EB-A2 008-012/10C4M45	0.80	4.00	1.20	45.00	10.0	0.75	0.40	2	30.0	C	0.010	0.0040-0.0080	•
EB-A2 010-015/03C4M45	1.00	4.00	1.50	45.00	3.0	0.97	0.50	2	30.0	C	0.010	0.0050-0.0100	•
EB-A2 010-015/04C4M45	1.00	4.00	1.50	45.00	4.0	0.97	0.50	2	30.0	C	0.010	0.0050-0.0100	•
EB-A2 010-015/05C4M45	1.00	4.00	1.50	45.00	5.0	0.97	0.50	2	30.0	C	0.010	0.0050-0.0100	•
EB-A2 010-015/06C4M45	1.00	4.00	1.50	45.00	6.0	0.97	0.50	2	30.0	C	0.010	0.0050-0.0100	•
EB-A2 010-015/07C4M45	1.00	4.00	1.50	45.00	7.0	0.95	0.50	2	30.0	C	0.010	0.0050-0.0100	•
EB-A2 010-015/08C4M45	1.00	4.00	1.50	45.00	8.0	0.95	0.50	2	30.0	C	0.010	0.0050-0.0100	•
EB-A2 010-015/10C4M45	1.00	4.00	1.50	45.00	10.0	0.95	0.50	2	30.0	C	0.010	0.0050-0.0100	•
EB-A2 010-015/12C4M45	1.00	4.00	1.50	45.00	12.0	0.93	0.50	2	30.0	C	0.010	0.0050-0.0100	•
EB-A2 010-015/14C4M50	1.00	4.00	1.50	50.00	14.0	0.93	0.50	2	30.0	C	0.010	0.0050-0.0100	•
EB-A2 010-015/16C4M50	1.00	4.00	1.50	50.00	16.0	0.93	0.50	2	30.0	C	0.010	0.0050-0.0100	•
EB-A2 010-015/20C4M55	1.00	4.00	1.50	55.00	20.0	0.93	0.50	2	30.0	C	0.010	0.0050-0.0100	•
EB-A2 012-018/08C4M45	1.20	4.00	1.80	45.00	8.0	1.17	0.60	2	30.0	C	0.010	0.0060-0.0150	•
EB-A2 012-018/12C4M45	1.20	4.00	1.80	45.00	12.0	1.13	0.60	2	30.0	C	0.010	0.0060-0.0150	•
EB-A2 014-021/08C4M45	1.40	4.00	2.10	45.00	8.0	1.35	0.70	2	30.0	C	0.010	0.0060-0.0150	•
EB-A2 014-021/16C4M50	1.40	4.00	2.10	50.00	16.0	1.31	0.70	2	30.0	C	0.010	0.0060-0.0150	•
EB-A2 015-015/03C04M50	1.50	4.00	1.50	50.00	3.0	1.47	0.75	2	30.0	C	0.010	0.0070-0.0160	•
EB-A2 015-023/06C4M45	1.50	4.00	2.30	45.00	6.0	1.47	0.75	2	30.0	C	0.010	0.0070-0.0160	•
EB-A2 015-023/08C4M45	1.50	4.00	2.30	45.00	8.0	1.45	0.75	2	30.0	C	0.010	0.0070-0.0160	•
EB-A2 015-023/10C4M45	1.50	4.00	2.30	45.00	10.0	1.45	0.75	2	30.0	C	0.010	0.0070-0.0160	•
EB-A2 015-023/12C4M45	1.50	4.00	2.30	45.00	12.0	1.43	0.75	2	30.0	C	0.010	0.0070-0.0160	•
EB-A2 015-023/20C4M55	1.50	4.00	2.30	55.00	20.0	1.39	0.75	2	30.0	C	0.010	0.0070-0.0160	•
EB-A2 016-024/08C4M45	1.60	4.00	2.40	45.00	8.0	1.55	0.80	2	30.0	C	0.010	0.0080-0.0170	•
EB-A2 016-024/12C4M45	1.60	4.00	2.40	45.00	12.0	1.53	0.80	2	30.0	C	0.010	0.0080-0.0170	•
EB-A2 018-027/08C4M45	1.80	4.00	2.70	45.00	8.0	1.75	0.90	2	30.0	C	0.010	0.0080-0.0180	•
EB-A2 018-027/12C4M45	1.80	4.00	2.70	45.00	12.0	1.73	0.90	2	30.0	C	0.010	0.0080-0.0180	•
EB-A2 018-027/16C4M50	1.80	4.00	2.70	50.00	16.0	1.71	0.90	2	30.0	C	0.010	0.0080-0.0180	•
EB-A2 020-030/04C4M45	2.00	4.00	3.00	45.00	4.0	1.97	1.00	2	30.0	C	0.010	0.0100-0.0210	•
EB-A2 020-030/06C4M45	2.00	4.00	3.00	45.00	6.0	1.97	1.00	2	30.0	C	0.010	0.0100-0.0210	•
EB-A2 020-030/10C4M45	2.00	4.00	3.00	45.00	10.0	1.93	1.00	2	30.0	C	0.010	0.0100-0.0210	•
EB-A2 020-030/12C4M50	2.00	4.00	3.00	50.00	12.0	1.93	1.00	2	30.0	C	0.010	0.0100-0.0210	•
EB-A2 020-030/14C4M50	2.00	4.00	3.00	50.00	14.0	1.93	1.00	2	30.0	C	0.010	0.0100-0.0210	•
EB-A2 020-030/16C4M50	2.00	4.00	3.00	50.00	16.0	1.91	1.00	2	30.0	C	0.010	0.0100-0.0210	•
EB-A2 020-030/20C4M55	2.00	4.00	3.00	55.00	20.0	1.89	1.00	2	30.0	C	0.010	0.0100-0.0210	•
EB-A2 020-030/25C4M60	2.00	4.00	3.00	60.00	25.0	1.89	1.00	2	30.0	C	0.010	0.0100-0.0210	•
EB-A2 020-030/30C4M70	2.00	4.00	3.00	70.00	30.0	1.89	1.00	2	30.0	C	0.010	0.0100-0.0210	•
EB-A2 030-045/08C6M50	3.00	6.00	4.50	50.00	8.0	2.85	1.50	2	30.0	C	0.010	0.0120-0.0300	•
EB-A2 030-045/10C6M50	3.00	6.00	4.50	50.00	10.0	2.85	1.50	2	30.0	C	0.010	0.0120-0.0300	•
EB-A2 030-045/12C6M50	3.00	6.00	4.50	50.00	12.0	2.85	1.50	2	30.0	C	0.010	0.0120-0.0300	•
EB-A2 030-045/16C6M55	3.00	6.00	4.50	55.00	16.0	2.85	1.50	2	30.0	C	0.010	0.0120-0.0300	•
EB-A2 030-045/20C6M60	3.00	6.00	4.50	60.00	20.0	2.85	1.50	2	30.0	C	0.010	0.0120-0.0300	•
EB-A2 030-045/25C6M65	3.00	6.00	4.50	65.00	25.0	2.85	1.50	2	30.0	C	0.010	0.0120-0.0300	•
EB-A2 030-045/30C6M70	3.00	6.00	4.50	70.00	30.0	2.85	1.50	2	30.0	C	0.010	0.0120-0.0300	•
EB-A2 030-045/35C6M80	3.00	6.00	4.50	80.00	35.0	2.85	1.50	2	30.0	C	0.010	0.0120-0.0300	•
EB-A2 040-060/10C6M60	4.00	6.00	6.00	60.00	10.0	3.80	2.00	2	30.0	C	0.010	0.0150-0.0350	•

Фрезерные инструменты Iscar 2026 - страница 205
