Фрезерные инструменты Iscar 2026 - страница 720

BT MAS-403 A 0.005 A AT3 Taper LPR 1 LBX 2 BT-EM-CX SS LBX DIN6359 / DIN 1835 Form B 58-60 HRc √N5 Weldon Endmill Holders with Jet Coolant Grooves for BT BD BD DCONWS DCONWS MAS-403 Tapered Shanks CRKS kg Designation SS DCONWS LPR BD LBX CRKS DCP(1) Fig. BT40 EM 6X50 CX 40 6.00 50.00 25.00 23.0 M16 0 1 1.07 SR M6X10 DIN1835B BT40 EM 8X50 CX 40 8.00 50.00 28.00 23.0 M16 0 1 1.09 SR M8X10 DIN1835-B BT40 EM 10X63 CX 40 10.00 63.00 35.00 36.0 M16 0 1 1.22 SR M10X12 DIN1835-B BT40 EM 12X63 CX 40 12.00 63.00 42.00 36.0 M16 0 1 1.26 SR M12X16 DIN1835-B BT40 EM 16X63 CX 40 16.00 63.00 48.00 36.0 M16 0 1 1.40 SR M14X16 DIN1835-B BT40 EM 20X63 CX 40 20.00 63.00 52.00 36.0 M16 0 1 1.40 SR M16X16 DIN1835-B BT40 EM 25X45 CX 40 25.00 45.00 61.00 18.0 M16 0 1 1.17 SR M18X2X10 EM SHORT BT40 EM 25X90 CX 40 25.00 90.00 65.00 63.0 M16 0 2 2.25 SR M18X2X20 DIN1835-B BT40 EM 32X100 CX 40 32.00 100.00 72.00 65.0 M16 0 2 2.70 SR M20X2X20 DIN1835-B BT50 EM 12X80 CX 50 12.00 80.00 42.00 42.0 M24 0 1 4.00 SR M12X16 DIN1835-B BT50 EM 16X80 CX 50 16.00 80.00 48.00 42.0 M24 0 1 4.10 SR M14X16 DIN1835-B BT50 EM 20X80 CX 50 20.00 80.00 52.00 42.0 M24 0 1 4.30 SR M16X16 DIN1835-B BT50 EM 25X100 CX 50 25.00 100.00 65.00 62.0 M24 0 2 5.60 SR M18X2X20 DIN1835-B BT50 EM 32X105 CX 50 32.00 105.00 72.00 67.0 M24 0 2 5.80 SR M20X2X20 DIN1835-B BT50 EM 40X110 CX 50 40.00 110.00 80.00 72.0 M24 0 2 5.20 SR M20X2X20 DIN1835-B (1) 1 - Slot for data chip, 0 - Without slot for data chip SS LB A 0.005 A AT3 Taper BT-FC-EM DIN1835 Form B Endmills 58-60 HRc √N5 BD BD_2 BD with BT MAS-403 Face CRKS DCONWS DCONWS Contact AD Tapered Shanks For DCONWS≥25 LBX LPR kg Designation SS DCONWS BD BD_2 LPR LBX LB CRKS DCP(1) BT30 FC EM12X60 30 12.00 42.00 - 60.00 38.0 - M12 0 0.73 BT30 FC EM16X60 30 16.00 45.90 - 60.00 38.0 - M12 0 0.80 BT30 FC EM20X80 30 20.00 52.00 44.40 80.00 58.0 48.00 M12 0 1.04 BT40 FC EM10X65 40 10.00 35.00 - 65.00 39.0 - M16 0 1.25 BT40 FC EM12X65 40 12.00 42.00 - 65.00 39.0 - M16 0 1.29 BT40 FC EM16X65 40 16.00 48.00 - 65.00 39.0 - M16 0 1.37 BT40 FC EM20X75 40 20.00 52.00 - 75.00 49.0 - M16 0 1.56 BT40 FC EM25X105 40 25.00 65.00 61.00 105.00 79.0 68.00 M16 0 2.54 BT40 FC EM32X110 40 32.00 71.00 61.00 110.00 83.0 73.00 M16 0 1.87 BT50 FC EM12X100 50 12.00 42.00 - 100.00 62.0 - M24 0 4.25 BT50 FC EM16X100 50 16.00 48.00 - 100.00 63.5 - M24 0 4.22 BT50 FC EM20X100 50 20.00 52.00 - 100.00 63.5 - M24 0 4.33 BT50 FC EM25X115 50 25.00 65.00 - 115.00 78.5 - M24 0 5.36 BT50 FC EM32X115 50 32.00 71.00 - 115.00 78.5 - M24 0 5.38 BT50 FC EM40X115 50 40.00 90.00 - 115.00 78.5 - M24 0 6.29 BT50 FC EM50X125 50 50.00 100.00 - 125.00 87.0 - M24 0 7.32 (1) 1 - Slot for data chip, 0 - Without slot for data chip BT-FC Face Contact Taper Face Contact Standard Spindle Spindle 802-805 Face Contact Standard Holder Holder 718 ISCAR
