EXTENDED FLUTE CUTTERS Shank T490 CAP-FT T490 LNK-BT-FT Basic Units of Modular Extended DC DF Flute Endmills with BT-MAS-403 Tapered Shanks Carrying T490 LNMT/HT 1306 Inserts APMX LBX LF kg Designation DC APMX LBX LF DF NOF(1) CICT(2) Shank T490LNK-D63-082-4-BT50-FT 63.00 82.00 107.0 145.00 100.00 4 28 BT-MAS-403 5.32 T490LNK-D80-105-4-BT50-FT 80.00 105.00 135.2 173.20 100.00 4 36 BT-MAS-403 7.35 • Remove coolant plug screws (SR M6X..DIN916) prior to attaching extension units (1) Number of flutes (2) Number of inserts (or edges for solid tool) For inserts, see pages: T490 LNAR-P (548) • T490 LNMT 1306PNTR-FW (547) • T490 LNMT/LNHT/LNAR 1306 (546) Shell Base Unit Extension DC APMX OAL NOF CICT NOFAssembly Screw 82 107 28 T490 LNK-D63-082-4-BT50-FT T490 CAP-D63-24-4-20-13FT 63 106 131 4 36 SR M12x30 DIN912 T490 CAP-D63-36-4-20-13FT 118 143 40 SR M12X45DIN912 12.9 105 135 36 T490 LNK-D80-105-4-BT50-FT T490 CAP-D80-24-4-25-13FT 80 129 159 4 44 SR M16x40 DIN912 T490 CAP-D80-36-4-25-13FT 141 171 48 SR M16x40 DIN912 Spare Parts Designation T490LNK-D63-082-4-BT50-FT SR 34-535-SN BLD T15/S7 SW6-T-SH SR M6X6 DIN916 SR M12X12 DIN912 T490LNK-D80-105-4-BT50-FT SR 34-535-SN BLD T15/S7 SW6-T-SH SR M6X8 DIN916 PG D63 SR M3X0.5X10DIN7991 10.9 287
