W1 MILLING INSERTS BS HM90 APCR 2206..R-P Super Positive Inserts Rd° with a Polished Rake for lNSL Machining Aluminum APMX S RE Recommended Dimensions Tough 1 Hard Machining Data ap fz IC28 IC08 Designation W1 RE APMX INSL BS S (mm) (mm/t) HM90 APCR 220605R-P 13.90 0.50 22.00 30.50 0.20 6.90 • 0.90-22.00 0.07-0.30 HM90 APCR 220608R-P 13.72 0.80 22.00 29.70 0.20 6.90 • • 1.20-22.00 0.07-0.30 HM90 APCR 220616R-P 13.72 1.60 22.00 29.70 0.20 6.90 • • 2.00-22.00 0.07-0.30 HM90 APCR 220623R-P 13.72 2.30 22.00 29.70 0.20 6.60 • • 2.70-22.00 0.07-0.30 HM90 APCR 220632R-P 13.72 3.20 22.00 29.40 0.20 6.60 • • 3.60-22.00 0.07-0.30 HM90 APCR 220640R-P 13.72 4.00 22.00 29.00 0.20 6.60 • • 4.40-22.00 0.07-0.30 HM90 APCR 220650R-P 13.72 5.00 22.00 28.20 0.20 6.10 • 5.40-22.00 0.07-0.30 HM90 APCR 220664R-P 13.72 6.40 22.00 26.80 0.20 6.00 • • 6.80-22.00 0.07-0.30 • For cutting speed recommendations, see pages 616-620 For tools, see pages: HM90 FAL-22 (440) W1 BS S HM90 APCR 220605-CS Chip Splitting Insert for Rd° Rough Milling of Aluminum lNSL APMX RE Dimensions Recommended Machining Data ap fz IC28 Designation W1 RE APMX INSL BS S (mm) (mm/t) HM90 APCR 220605-CS 14.60 0.50 22.00 30.90 0.30 6.90 • 22.00-22.00 (1) 0.25-0.35 • To avoid incorrect mounting of the inserts, insert one pin into each tool pocket in an alternating order. As there is only one cavity at the insert bottom, this will prevent incorrect insert orientation. • To be used only on even number flute tools, when the “1” and “2” digits appear in an alternating order. • For cutting speed recommendations, see pages 616-620 (1) Machine with maximum depth of cut For tools, see pages: HM90 FAL-22 (440) S HSM90S APCR 2207 Super Positive Inserts INSL with a Polished Rake for APMX Machining Aluminum at High Rotational Speed Rd° BS RE W1 Dimensions Recommended Machining Data ap fz IC08 Designation W1 RE(1) APMX BS INSL S (mm) (mm/t) HSM90S APCR 220708R-P 13.10 0.80 22.00 5.00 29.20 6.90 • 1.20-22.00 0.15-0.30 HSM90S APCR 220716R-P 13.10 1.60 22.00 4.20 29.10 6.90 • 2.00-22.00 0.15-0.30 HSM90S APCR 220720R-P 13.10 2.00 22.00 3.90 29.10 6.80 • 2.40-22.00 0.15-0.30 HSM90S APCR 220730R-P 13.10 3.00 22.00 2.90 29.00 6.70 • 3.40-22.00 0.15-0.30 HSM90S APCR 220732R-P 13.10 3.20 22.00 2.70 29.00 6.70 • 3.60-22.00 0.15-0.30 HSM90S APCR 220740R-P 13.10 4.00 22.00 1.90 29.00 6.60 • 4.40-22.00 0.15-0.30 HSM90S APCR 220750R-P 13.10 5.00 22.00 0.90 28.90 6.50 • 5.40-22.00 0.15-0.30 • When machining at very high cutting speed it is recommended to replace the screw when replacing the insert • For cutting speed recommendations, see pages 616-620 (1) Measured on the cutter For tools, see pages: HSM90S FAL-22 (441) • HSM90SFD-HSK A63/80-22 (441) 535
