CUTTERS FOR ALUMINUM DHUB DCONMS HSM90S FAL-22 90° Face Mills Carrying Super Rd° Positive and Polished Rake OAL Inserts for Machining Aluminum at High Rotation Speeds APMX DC kg Designation DC APMX CICT(1) DCONMS DHUB OAL Arbor(2) RMPX°(3) RPMX(4) MIID(5) HSM90S FAL-D050-3-22-22 50.00 22.00 3 22.00 48.00 57.00 A 7.0 31000 HSM90S APCR 2207 0.40 HSM90S FAL-D050-4-22-22 50.00 22.00 4 22.00 48.00 57.00 A 7.0 31000 HSM90S APCR 2207 0.41 • Important: When machining at very high cutting speeds it is recommended to replace the screw when replacing the insert • Insert tightening torque: 6 (Nxm) (1) Number of inserts (or edges for solid tool) (2) For adaptation options, see page 622 (3) Maximum ramping angle (4) Maximum RPM (5) Master insert identification For inserts, see pages: HSM90S APCR 2207 (535) Spare Parts Designation HSM90S FAL-22 SR M5x0.8 20IP-13343 BLD IP20/M7 SW6-T-SH SR M10X40DIN912 LF Rd° LH HSM90SFD-HSK A63/80-22 LU 90° Endmills with Integral HSK Adaptation Carrying DC DCONMS Super Positive Inserts for Machining Aluminum at G2.5 APMX 31,000 RPM High Rotation Speeds or U<1.0 gmm 6 x M6 threaded holes for balancing screws kg Designation DC APMX LU LH LF CICT(1) DCONMS Shank RMPX°(2) RPMX(3) DCP(4) MIID(5) HSM90SFD50-3-63A/80MQL-22 50.00 22.00 73.10 84.0 110.00 3 80.00 HSK A63/80 7.0 31000 1 1.93 HSM90S APCR 220708R HSM90SFD50-4-63A/80MQL-22 50.00 22.00 73.10 84.0 110.00 4 80.00 HSK A63/80 7.0 31000 1 1.93 HSM90S APCR 220708R • A cooling tube must be used with all internal coolant HSK spindles (to be order separately • Important: When machining at very high cutting speeds and the insert needs replacing, it is also recommended to replace the screws • Kit balancing screws to be order separately • Insert tightening torque: 6 (Nxm) (1) Number of inserts (or edges for solid tool) (2) Maximum ramping angle (3) Maximum RPM (4) 1 - Slot for data chip, 0 - Without slot for data chip (5) Master insert identification For inserts, see pages: HSM90S APCR 2207 (535) Spare Parts Designation HSM90SFD-HSK A63/80-22 SR M5x0.8 20IP-13343 BLD IP20/M7 SW6-T-SH COOLING TUBE HSK A63 441
