SLOTTING & SLITTING CUTTERS LF 3 Typ. SW/S DCONWS Drive Shanks for SELF-GRIP Slitting Cutters Screw BD DBC DCONMS DBC DCONMS BD LPR DCONWS LF SW- Type S- Type SW20 Designation DCONMS BD DBC DCONWS LPR LF kg SW 20 20.00 20.00 14.40 8.00 - 100.00 0.24 SW 25-23 25.00 23.00 13.60 6.00 25.0 110.00 0.00 SW 25-28 25.00 28.00 18.00 8.00 25.0 110.00 0.43 SW 25-32 25.00 32.00 22.00 10.00 25.0 110.00 0.51 SW 32-40 32.00 40.00 32.00 22.00 30.0 120.00 0.60 S 32-55 32.00 55.00 45.00 32.00 - 60.00 2.22 S 40-80 40.00 80.00 63.00 40.00 - 60.00 1.78 For tools, see pages: GM-DG (423) • SGSA (420) • SGSF (418) • TGSF (412) Spare Parts Designation SW 20 SR M5X20 DIN7991 HW 3.0 SW 25-23 SR 34-510 T-15/5 SW 25-28 SR 76-961 T-15/5 SW 25-32 SR 76-961 T-15/5 SW 32-40 SR 76-963 T-15/5 S 32-55 SR 76-943 BLD T20/M7 SW6-T S 40-80 SR 76-944 HW 6.0 DCONMS LB D4 R (drive flange set) Drive Flange Set for Slitting Cutters BD DBC Designation DCONMS BD DBC D4 LB R 22-46 22.00 46.00 32.00 5.00 10.00 R 32-55 32.00 55.00 45.00 6.00 10.00 R 40-80 40.00 80.00 63.00 11.00 12.00 R 50-110 50.00 110.00 80.00 14.00 14.00 DBC C#-SW Holders with CAMFIX DCONMS DCONWS BD Exchangeable Shanks for SELF/ TANG-GRIP Slitting Cutters LB LPR Designation DCONMS DCONWS BD DBC LPR LB C3 S8-28-40 32.00 8.00 28.00 18.00 40.0 23.00 C4 S22-40-50 40.00 22.00 40.00 32.00 50.0 - C5 S32-55-50 50.00 32.00 55.00 45.00 50.0 28.10 C8 S40-80-50 80.00 40.00 80.00 63.00 50.0 - For tools, see pages: GM-DG (423) • SGSA (420) • SGSF (418) • TGSF (412) DBC MB-SW MB Modular Connection DCONMS DCONWS BD System for SELF/TANG-GRIP Slitting Cutters LB LPR Designation DCONMS DCONWS BD DBC LPR LF STH S8-28-40 MB32 32.00 8.00 28.00 18.00 40.0 23.00 STH S10-32-40 MB32 32.00 10.00 32.00 22.00 40.0 - STH S22-40-50 MB40 40.00 22.00 40.00 32.00 50.0 - STH S32-55-50 MB50 50.00 32.00 55.00 45.00 50.0 27.50 STH S40-80-50 MB80 80.00 40.00 80.00 63.00 50.0 - For tools, see pages: GM-DG (423) • SGSA (420) • SGSF (418) • TGSF (412) 419
