DIN69871-A/B SS THSZWS RE MM S-A-SK BD DIN 69871 Integral Tapered Shanks Mount MULTI-MASTER LU CRKS LBX Milling Heads LPR kg Designation SS CRKS THSZWS BD LPR LBX LU RE MM S-A-H040-SK 40-T06 40 M16 T06 9.25 40.00 21.0 15.00 6.0 0.86 MM S-A-H045-SK 40-T08 40 M16 T08 11.60 45.00 26.0 20.00 6.0 0.87 MM S-A-H050-SK 40-T10 40 M16 T10 15.30 50.00 31.0 25.00 6.0 0.83 MM S-A-H050-SK 40-T12 40 M16 T12 18.30 50.00 31.0 25.00 6.0 0.90 MM S-A-H050-SK 40-T15 40 M16 T15 23.90 50.00 31.0 25.00 6.0 0.09 • Do not apply lubricant to the threaded connection • For adaptation, see page 746 802-805 LPR A 0.003 A AT3 Taper 58-60 HRc √N5 LBX DIN69871-ODP SS LB FLEX-FIT Threaded Connection BD_2 10 G2.5 SK 40=20,000 RPM Shanks with Integral DIN 69871 or U<1.0 gmm G6.3 BD Form ADB Taper Adaptation SK 50=12,000 RPM CRKS THSZWS kg Designation SS THSZWS BD BD_2 LPR LBX LB CRKS DCP(1) DIN69871 40 ODP 6X58 40 M06 9.80 13.00 58.00 38.9 30.00 M16 0 0.82 DIN69871 40 ODP 6X98 40 M06 9.80 23.00 98.00 78.9 70.00 M16 0 0.91 DIN69871 40 ODP 8X58 40 M08 13.10 15.00 58.00 38.9 30.00 M16 0 0.82 DIN69871 40 ODP 8X98 40 M08 13.10 23.00 98.00 78.9 70.00 M16 0 0.92 DIN69871 40 ODP10X58 40 M10 18.00 20.00 58.00 38.9 30.00 M16 0 0.84 DIN69871 40 ODP10X98 40 M10 18.00 28.00 98.00 78.9 70.00 M16 0 1.00 DIN69871 40 ODP12X58 40 M12 21.00 24.00 58.00 38.9 30.00 M16 0 0.88 DIN69871 40 ODP12X98 40 M12 21.00 31.00 98.00 78.9 70.00 M16 0 1.07 DIN69871 40 ODP16X58 40 M16 29.00 28.60 58.00 38.9 35.00 M16 0 0.91 DIN69871 40 ODP16X98 40 M16 29.00 34.00 98.00 78.9 70.00 M16 0 1.15 DIN69871 50 ODP12X 78 50 M12 23.00 30.00 78.00 58.9 50.00 M24 0 2.74 DIN69871 50 ODP12X128 50 M12 23.00 40.00 128.00 108.9 100.00 M24 0 3.14 DIN69871 50 ODP12X178 50 M12 23.00 40.00 178.00 158.9 150.00 M24 0 3.38 DIN69871 50 ODP12X228 50 M12 23.00 46.00 228.00 208.9 200.00 M24 0 4.19 DIN69871 50 ODP16X 78 50 M16 29.00 34.00 78.00 58.9 50.00 M24 0 2.95 DIN69871 50 ODP16X128 50 M16 29.00 40.00 128.00 108.9 100.00 M24 0 3.20 DIN69871 50 ODP16X178 50 M16 29.00 55.00 178.00 158.9 150.00 M24 0 4.08 DIN69871 50 ODP16X228 50 M16 29.00 55.00 228.00 208.9 200.00 M24 0 4.64 (1) 1 - Slot for data chip, 0 - Without slot for data chip 802-805 747-749 746 657
